| 1-25. | VAME087587 | [1] | STARTER MOTOR | KOB24V-5.5KW MEC M00T95172 Superseded by part number: VAME049304 |
| . . | VAME049304R | [1] | REMAN-STARTER | KOBMD200C BTW YQU0701 - YQU2000, Reman For New P/N VAME087587, N.A. Only |
| . . | VAME049304C | [1] | CORE-STARTER | KOBReturn Number, For N.A. Only |
| 1. | VAME700276 | [1] | SET OF SCREWS | KOBMEC M414X06671 |
| 1A. | VAME700280 | [2] | SCREW | KOBSCREW FLANGE MEC M986C10102 |
| 2. | VAME701093 | [1] | RELAY | KOBSWITCH ASSY MEC U001T07079 Superseded by part number: VAU001T07079 |
| 3. | VAME700889 | [1] | SWITCH | KOBASSY MEC M371X21271 Superseded by part number: VAM371X21271 |
| 4. | VAME700884 | [1] | LEVER | KOBMEC M863C06672 |
| 4A. | VAME700287 | [1] | BRACKET GEAR MEC M646C71001 | BRACKET GEAR MEC M646C71001 |
| 5. | VAME700285 | [1] | PACKING | KOBMEC M578C22201 Superseded by part number: ME700285 |
| 6-7. | VAME700286 | [1] | SHAFT | KOBGEAR MEC M357X61571 Superseded by part number: 135057A1 |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR, INTERNAL |
| 7. | VAME700072 | [1] | BEARING | KOBGEAR MEC S930P28370 Superseded by part number: 135038A1 |
| 8. | VAME700022 | [1] | WASHER | KOBWASHER SET MEC M900X02071 Superseded by part number: 135071A1 |
| 9. | VAME700288 | [1] | U-BRACKET | KOBASSY, CTR MEC M646B22301 Superseded by part number: 135048A1 |
| 10-12. | VAME700321 | [1] | ARMATURE | KOBASSY MEC M106X40471 Superseded by part number: 77269913, 135036A1 |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONARMATURE |
| 11. | VAME700038 | [1] | BEARING | KOBCTR MEC S930P12370 Superseded by part number: 135040A1 |
| 12. | VAME700039 | [1] | BEARING | KOBRE MEC S930P28070 Superseded by part number: VAS930P28001 |
| 13. | VAME700291 | [1] | BOLT | KOBMEC M981X76071 Superseded by part number: VAM981X76071 |
| 14. | VAME700885 | [1] | BRACKET ASSY FR MEC M641X70671 | BRACKET ASSY FR MEC M641X70671 |
| 15. | VAME700862 | [1] | BUSHING | KOBSLEEVE SET MEC M410X13872 Superseded by part number: VAM410X13872 |
| 16. | VAME700886 | [1] | SOCKET | KOBMEC M385X04172 |
| 17. | VAME700887 | [1] | CLUTCH | KOBOVER RUNNING MEC M191T66071 |
| 20. | VAME700875 | [1] | GASKET | KOBMEC M578X14572 Superseded by part number: 135063A1 |
| 21. | VAME701137 | [1] | YOKE | KOBMEC M800X44673 |
| 22-23. | VAME700047 | [1] | HOLDER BRUSH ASSY MEC M649T04971 | HOLDER BRUSH ASSY MEC M649T04971 |
| 22. | NSS | [1] | NOT SOLD SEPARAT | CONHOLDER, BRUSH |
| 23. | VAMD607462 | [4] | SPRING SPRING, BRUSH MEC M391C02201 | SPRING SPRING, BRUSH MEC M391C02201 |
| 24. | VAME700048 | [1] | U-BRACKET | KOBASSY MEC M644B20701 Superseded by part number: 135050A1 |
| 25. | VAME700026 | [2] | SEAL RETAINER | KOBMEC M816D00701 Superseded by part number: 135064A1 |
