现代零件查询R75-7 POWER UNIT 1EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
588 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01866
|
[1] |
ENGINE ASSY
|
|
| 2. |
XJDH-01868
|
[1] |
BRACKET-ENGINE(A)
|
|
| 3. |
XJDH-01867
|
[1] |
BRACKET-ENGINE(B)
|
|
| 4. |
XJDH-00072
|
[8] |
BOLT
|
|
| 5. |
XJDH-00280
|
[8] |
WASHER
|
|
| 6. |
XJDH-00855
|
[1] |
COUPLING
|
|
| 7. |
XJDH-01574
|
[1] |
BOSS-COUPLING
|
|
| 8. |
XJDH-00133
|
[6] |
BOLT-SOCKET HEAD
|
|
| 9. |
XJDH-01869
|
[1] |
PUMP FLANGE ASSY
|
|
| 10. |
XJDH-00059
|
[10] |
BOLT
|
|
| 11. |
XJDH-00278
|
[10] |
WASHER
|
|
| 12. |
XJDH-00808
|
[2] |
PLATE-DEPPING
|
|
| 13. |
XJDH-00085
|
[4] |
BOLT
|
|
| 14. |
XJDH-00283
|
[4] |
WASHER
|
|
| 15. |
XJDH-00859
|
[4] |
RUBBER-ABSORBER
|
|
| 16. |
XJDH-00858
|
[4] |
RUBBER-ABSORBER
|
|
| 17. |
XJDH-00050
|
[4] |
BOLT
|
|
| 18. |
XJDH-01176
|
[4] |
WASHER
|
|
| 19. |
XJDH-02835
|
[1] |
CORD-GROUND
|
|
| 20. |
XJDH-00055
|
[2] |
BOLT
|
|
| 21. |
XJDH-00278
|
[2] |
WASHER
|
|
| 22. |
XJDH-01883
|
[1] |
MUFFLER
|
|
| 23. |
XJDH-01879
|
[1] |
GASKET
|
|
| 24. |
XJDH-01887
|
[2] |
BAND
|
|
| 25. |
XJDH-01888
|
[2] |
BAND
|
|
| 26. |
XJDH-00042
|
[2] |
BOLT
|
|
| 27. |
XJDH-00034
|
[2] |
BOLT
|
|
| 28. |
XJDH-00186
|
[4] |
NUT
|
|
| 29. |
XJDH-00276
|
[4] |
WASHER
|
|
| 30. |
XJDH-01870
|
[1] |
PIPE-EXHAUST
|
|
| 30. |
XJDH-04310
|
[1] |
PIPE, EXHAUST
|
|
| 31. |
XJDH-01877
|
[1] |
GASKET
|
|
| 32. |
XJDH-00187
|
[6] |
NUT
|
|
| 33. |
XJDH-00278
|
[6] |
WASHER
|
|
| 34. |
XJDH-01944
|
[1] |
BRACKET ASSY
|
|
| 35. |
XJDH-00057
|
[8] |
BOLT
|
|
| 36. |
XJDH-00278
|
[8] |
WASHER
|
|
| 37. |
XJDH-01582
|
[1] |
BRACKET-ACCEL LEVER
|
|
| 38. |
XJDH-00057
|
[1] |
BOLT
|
|
| 39. |
XJDH-00278
|
[1] |
WASHER
|
|
| 40. |
XJDH-00051
|
[2] |
BOLT
|
|
| 41. |
XJDH-00184
|
[2] |
NUT
|
|
| 42. |
XJDH-01585
|
[1] |
LEVER-ACCEL
|
|
| 43. |
XJDH-00032
|
[1] |
BOLT
|
|
| 44. |
XJDH-00276
|
[1] |
WASHER
|
|
| 45. |
XJDH-01584
|
[1] |
SHAFT
|
|
| 46. |
XJDH-00288
|
[4] |
WASHER-CONICAL
|
|
| 47. |
XJDH-00283
|
[3] |
WASHER
|
|
| 48. |
XJDH-00173
|
[2] |
NUT
|
|
| 49. |
XJDH-01048
|
[1] |
GRIP
|
|
| 50. |
XJDH-02849
|
[1] |
WIRE-PUSH PULL
|
|
| 51. |
XJDH-00182
|
[2] |
NUT
|
|
| 52. |
XJDH-01010
|
[2] |
CLEVIS
|
|
| 53. |
XJDH-01011
|
[2] |
PIN-CLEVIS
|
|
| 54. |
XJDH-00292
|
[2] |
PIN-SPLIT
|
|
| 55. |
XJDH-01905
|
[1] |
BRACKET-ACCEL WIRE
|
|
| 56. |
XJDH-01906
|
[1] |
PIN-CLEVIS
|
|
| 57. |
XJDH-00712
|
[1] |
STRIP-WEATHER
|
|
| 58. |
XJDH-01894
|
[1] |
FILTER-OIL
|
|
| 59. |
XJDH-01949
|
[1] |
V-BELT
|
|
| 60. |
XJDH-01950
|
[1] |
ALTERNATOR ASSY
|
|
| 61. |
XJDH-01951
|
[1] |
STARTER ASSY
|
|
