现代零件查询R75-7 POWER UNIT 2EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
404 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01882
|
[1] |
RADIATOR ASSY
|
|
| 2. |
XJDH-01938
|
[2] |
CUSHION-RADIATOR
|
|
| 3. |
XJDH-00024
|
[2] |
BOLT
|
|
| 4. |
XJDH-00274
|
[2] |
WASHER
|
|
| 5. |
XJDH-01872
|
[1] |
BRACKET-RADIATOR
|
|
| 6. |
XJDH-01936
|
[1] |
FOAM ASSY-URETHAN
|
|
| 7. |
XJDH-00758
|
[2] |
FOAM-URETHAN
|
|
| 8. |
XJDH-00750
|
[1] |
FOAM-URETHAN
|
|
| 9. |
XJDH-00728
|
[3] |
FOAM-URETHAM
|
|
| 10. |
XJDH-00754
|
[1] |
FOAM-URETHAN
|
|
| 11. |
XJDH-00749
|
[2] |
FOAM-URETHAN
|
|
| 12. |
XJDH-00746
|
[1] |
FOAM-URETHAN
|
|
| 13. |
XJDH-00752
|
[2] |
FOAM-URETHAN
|
|
| 14. |
XJDH-00741
|
[2] |
FOAM-URETHAN
|
|
| 15. |
XJDH-01910
|
[1] |
PLATE
|
|
| 16. |
XJDH-00137
|
[2] |
BOLT-WING
|
|
| 17. |
XJDH-01935
|
[1] |
PLATE
|
|
| 18. |
XJDH-00698
|
[1] |
GROMMET
|
|
| 19. |
XJDH-00071
|
[4] |
BOLT
|
|
| 20. |
XJDH-00280
|
[4] |
WASHER
|
|
| 21. |
XJDH-01941
|
[1] |
BAFFLE
|
|
| 22. |
XJDH-00034
|
[7] |
BOLT
|
|
| 23. |
XJDH-00276
|
[7] |
WASHER
|
|
| 24. |
XJDH-01871
|
[1] |
SHROUD
|
|
| 25. |
XJDH-00018
|
[4] |
BOLT
|
|
| 26. |
XJDH-00274
|
[4] |
WASHER
|
|
| 27. |
XJDH-01762
|
[1] |
GUARD-FAN
|
|
| 28. |
XJDH-00035
|
[3] |
BOLT
|
|
| 29. |
XJDH-00276
|
[3] |
WASHER
|
|
| 30. |
XJDH-01880
|
[2] |
COOLER ASSY-OIL
|
|
| 31. |
XJDH-00034
|
[8] |
BOLT
|
|
| 32. |
XJDH-00276
|
[8] |
WASHER
|
|
| 33. |
XJDH-01908
|
[1] |
PLATE
|
|
| 34. |
XJDH-00034
|
[2] |
BOLT
|
|
| 35. |
XJDH-00276
|
[2] |
WASHER
|
|
| 36. |
XJDH-01878
|
[1] |
CONDENSOR TANK KIT
|
|
| 37. |
XJDH-02784
|
[2] |
BOLT
|
|
| 38. |
XJDH-00276
|
[2] |
WASHER
|
|
| 39. |
XJDH-01943
|
[1] |
HOSE-UPPER
|
|
| 40. |
XJDH-01942
|
[1] |
HOSE-LOWER
|
|
| 41. |
XJDH-00570
|
[2] |
BAND-WIRE
|
|
| 42. |
XJDH-00575
|
[2] |
CLAMP-HOSE
|
|
| 43. |
XJDH-00562
|
[1] |
HOSE-VINYL
|
|
| 44. |
XJDH-00582
|
[1] |
CLIP
|
|
| 45. |
XJDH-00533
|
[1] |
HOSE-RUBBER
|
|
| 46. |
XJDH-00585
|
[3] |
CLIP
|
|
| 47. |
XJDH-00532
|
[1] |
HOSE-RUBBER
|
|
| 48. |
XJDH-01873
|
[1] |
VALVE-BALL
|
|
