现代零件查询R75-7 POWER UNIT 4EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
300 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-00546
|
[1] |
HOSE
|
|
| 2. |
XJDH-00545
|
[1] |
HOSE
|
|
| 3. |
XJDH-00524
|
[4] |
BAND
|
|
| 4. |
XJDH-01895
|
[1] |
ELEMENT ASSY
|
|
| 5. |
XJDH-01948
|
[1] |
ELEMENT
|
|
| 6. |
XJDH-00807
|
[1] |
PLATE-DEPPING
|
|
| 7. |
XJDH-00034
|
[1] |
BOLT
|
|
| 8. |
XJDH-00276
|
[1] |
WASHER
|
|
| 9. |
XJDH-04311
|
[1] |
BRACKET
|
|
| 10. |
XJDH-00037
|
[1] |
BOLT
|
|
| 11. |
XJDH-00035
|
[1] |
BOLT
|
|
| 12. |
XJDH-00276
|
[2] |
WASHER
|
|
| 13. |
XJDH-04312
|
[1] |
FUEL PUMP
|
|
| 14. |
XJDH-00024
|
[2] |
BOLT
|
|
| 15. |
XJDH-00274
|
[3] |
WASHER
|
|
| 16. |
XJDH-00021
|
[1] |
BOLT
|
|
| 17. |
XJDH-04313
|
[1] |
HOSE
|
|
| 18. |
XJDH-02942
|
[2] |
BAND
|
|
| 19. |
XJDH-04314
|
[1] |
HARNESS
|
|
