纽荷兰零件查询(65B) - MOTORGRADERS (A2.43[001]) - COLD WEATHER STARTING AID New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
229 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73132158 | [1] | CYLINDER | CMI |
| 2. | 70669359 | [1] | BRACKET | BHBCLAMP |
| 3. | 73121585 | [1] | HYDRAULIC VALVE | CMIVALVE, ELECTRO |
| . . | 70929002 | [2] | SCREW | CMICAPSCREW,t/4""NCX3/8» |
| . . | 70904204 | [2] | LOCK WASHER | CMILOCKWASHER,1/4"" Superseded by part number: 80682 |
| 4. | 73121530 | [2] | TERMINAL | CMIWIRE |
| 5. | 73121529 | [1] | HYD CONNECTOR | CMICONNECTOR |
| 6. | 73121586 | [1] | GUARD | CMITHERMOGUARD Superseded by part number: 73123219 |
| . . | 15970330 | [1] | SCREW | MKTCAPSCREW.M10X1.25X16 Superseded by part number: 15970331 |
| . . | 10516870 | [1] | LOCK WASHER | MKTLOCKWASHER.M10 Superseded by part number: 10571873 |
| 7. | 73119888 | [1] | WIRE HARNESS | CMIWIRE |
| 8. | 73115559 | [1] | SWITCH | CMI |
| 10. | 73119879 | [1] | ELECTRIC CABLE | CMIWIRE Superseded by part number: 73140590 |
| 11. | 70196765 | [1] | CABLE RETAINER | BHBTIE Superseded by part number: 75201642 |
| 12. | 73115566 | [1] | SPARE PART,0.063" ID, 0.25" OD, 48" Length | CMITUBE Superseded by part number: 73110484 |
| . . | 70911841 | [2] | CONE TYPE FERRULE | BHBSLEEVE, 1/8"" |
| . . | 70912589 | [2] | NUT | BHB1/8"" |
| . . | 73052086 | [1] | ELBOW | BHB Superseded by part number: 70917310 |
| 13. | 73121066 | [1] | NOZZLE | CMIATOMIZER Superseded by part number: 9701049 |
| . . | 70904269 | [1] | BUSHING | CMI1/2""-1/8""NPT |
