久保田零件查询T03200 3RD 5TH PTO SHAFT TRANSMISSIONEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
223 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
6620414310
|
[1] |
SHAFT 3
|
1.5400(lbs); 0.700
|
| 002. |
0810106303
|
[1] |
BEARING BALL
|
0.2464(lbs); 0.112
|
| 003. |
0810106205
|
[1] |
BEARING BALL
|
0.2640(lbs); 0.120
|
| 004. |
0461100470
|
[1] |
CIR-CLIP INTERNAL
|
0.0132(lbs); 0.006
|
| 005. |
0461100520
|
[1] |
CIR-CLIP INTERNAL
|
0.0198(lbs); 0.009
|
| 006. |
6620414320
|
[1] |
GEAR 21-17
|
0.0000(lbs); 0.000
|
| 007. |
6620414330
|
[1] |
COLLAR
|
0.0660(lbs); 0.030
|
| 008. |
6670614380
|
[2] |
CAM
|
0.4356(lbs); 0.198
|
| 009. |
6213114170
|
[1] |
SHIM
|
0.0044(lbs); 0.002
|
| 010. |
0461200220
|
[1] |
CIR-CLIP EXTERNAL
|
0.0022(lbs); 0.001
|
| 011. |
6670614510
|
[1] |
SHAFT 5
|
0.0000(lbs); 0.000
|
| 012. |
0810106205
|
[1] |
BEARING BALL
|
0.2640(lbs); 0.120
|
| 013. |
0810106303
|
[1] |
BEARING BALL
|
0.2464(lbs); 0.112
|
| 014. |
0461200250
|
[1] |
CIR-CLIP EXTERNAL
|
0.0044(lbs); 0.002
|
| 015. |
6620414510
|
[1] |
GEAR SPUR 14
|
0.2970(lbs); 0.135
|
| 016. |
6620414710
|
[1] |
SHAFT PTO
|
0.0000(lbs); 0.000
|
| 017. |
0871130204
|
[1] |
BEARING
|
0.2552(lbs); 0.116
|
| 018. |
0871130205
|
[1] |
BEARING
|
0.3256(lbs); 0.148
|
| 019. |
6670414720
|
[1] |
WASHER
|
0.0198(lbs); 0.009
|
| 020. |
0918035488
|
[1] |
SEAL OIL
|
0.0418(lbs); 0.019
|
| 021. |
6620414790
|
[1] |
GEAR SPUR 21
|
1.0230(lbs); 0.465
|
| 022. |
6661114730
|
[1] |
BUSH
|
0.0924(lbs); 0.042
|
| 023. |
6670614740
|
[1] |
COLLAR
|
0.0660(lbs); 0.030
|
| 024. |
6661114750
|
[1] |
SHIM 1
|
0.0044(lbs); 0.002
|
| 024. |
6661114760
|
[1] |
SHIM 2
|
0.0044(lbs); 0.002
|
| 024. |
6661114770
|
[1] |
SHIM 3
|
0.0022(lbs); 0.001
|
| 025. |
6670614810
|
[1] |
VINYL COVER PTO
|
0.0528(lbs); 0.024
|
| 026. |
6375332430
|
[1] |
WASHER
|
0.0022(lbs); 0.001
|
| 027. |
6670414730
|
[1] |
BOLT
|
0.0264(lbs); 0.012
|
| 028. |
6670614390
|
[1] |
SPRING
|
0.0990(lbs); 0.045
|
| 029. |
6670614520
|
[1] |
BUSH
|
0.0088(lbs); 0.004
|
| 030. |
6670614782
|
[1] |
COLLAR
|
0.0132(lbs); 0.006
|
| 031. |
0401250080
|
[1] |
WASHER PLAIN
|
0.0022(lbs); 0.001
|
| 032. |
6661114740
|
[1] |
COLLAR
|
0.0022(lbs); 0.001
|
