现代零件查询R75-7 CONTROL SYSTEM 4EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
314 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01580
|
[1] |
PLATE(A)-FLOOR
|
|
| 2. |
XJDH-00035
|
[5] |
BOLT
|
|
| 3. |
XJDH-00276
|
[5] |
WASHER
|
|
| 4. |
XJDH-00058
|
[8] |
BOLT
|
|
| 5. |
XJDH-00278
|
[8] |
WASHER
|
|
| 6. |
XJDH-01576
|
[1] |
LEVER ASSY-DRIVE,LH
|
|
| 7. |
XJDH-01577
|
[1] |
LEVER ASSY-DRIVE,RH
|
|
| 8. |
XJDH-00057
|
[4] |
BOLT
|
|
| 9. |
XJDH-00278
|
[4] |
WASHER
|
|
| 10. |
XJDH-01005
|
[2] |
GRIP
|
|
| 11. |
XJDH-00171
|
[2] |
NUT
|
|
| 12. |
XJDH-01591
|
[1] |
PEDAL-PTO
|
|
| 13. |
XJDH-00035
|
[2] |
BOLT
|
|
| 14. |
XJDH-00276
|
[2] |
WASHER
|
|
| 15. |
XJDH-01593
|
[1] |
COVER(L)-PEDAL
|
|
| 16. |
XJDH-01595
|
[1] |
PEDAL-SWING
|
|
| 17. |
XJDH-00035
|
[2] |
BOLT
|
|
| 18. |
XJDH-00276
|
[2] |
WASHER
|
|
| 19. |
XJDH-01596
|
[1] |
COVER(R)-PEDAL
|
|
| 20. |
XJDH-01594
|
[1] |
NONSLIP
|
|
| 21. |
XJDH-01205
|
[1] |
NONSLIP
|
|
| 22. |
XJDH-01208
|
[1] |
NONSLIP
|
|
| 23. |
XJDH-01575
|
[2] |
NONSLIP
|
|
| 24. |
XJDH-01592
|
[1] |
NONSLIP
|
|
| 25. |
XJDH-00703
|
[1] |
FOOT-RUBBER
|
|
| 26. |
XJDH-00207
|
[1] |
SCREW-PAN HEAD
|
|
| 27. |
XJDH-00236
|
[1] |
WASHER-SPRING
|
|
| 28. |
XJDH-00250
|
[1] |
WASHER
|
|
