久保田零件查询T07000 REAR WHEEL [DP-CA DP/EP-OVERSEAS] REAR AXLE/REAR WHEELEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
848 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
9601804010
|
[1] |
ASSY REAR WHEEL 8-16
|
127.6000(lbs); 58.00
|
| 002. |
9601804100
|
[1] |
ASSY REAR WHEEL LH
|
77.0000(lbs); 35.000
|
| 003. |
6670417150
|
[1] |
HUB WHEEL
|
5.7200(lbs); 2.600
|
| 005. |
0207650140
|
[6] |
NUT
|
0.0484(lbs); 0.022
|
| 006. |
0451250140
|
[6] |
WASHER SPRING
|
0.0154(lbs); 0.007
|
| 007. |
0401350140
|
[6] |
WASHER PLAIN
|
0.0220(lbs); 0.010
|
| 008. |
3350049030
|
[1] |
WHEEL
|
24.2000(lbs); 11.000
|
| 008. |
3650049030
|
[1] |
WHEEL
|
24.2000(lbs); 11.000
|
| 009. |
3780043750
|
[1] |
TUBE
|
3.3000(lbs); 1.500
|
| 010. |
3780043740
|
[1] |
TIRE
|
32.7800(lbs); 14.900
|
| 011. |
3215027700
|
[1] |
ASSY VALVE
|
0.0022(lbs); 0.001
|
| 012. |
3227011650
|
[1] |
CORE VALVE
|
0.0044(lbs); 0.002
|
| 013. |
3215027740
|
[1] |
CAP
|
0.0066(lbs); 0.003
|
| 014. |
9601804200
|
[1] |
ASSY REAR WHEEL RH
|
77.0000(lbs); 35.000
|
| 015. |
6670417150
|
[1] |
HUB WHEEL
|
5.7200(lbs); 2.600
|
| 016. |
0107351435
|
[6] |
BOLT
|
0.1386(lbs); 0.063
|
| 017. |
0207650140
|
[6] |
NUT
|
0.0484(lbs); 0.022
|
| 018. |
0451250140
|
[6] |
WASHER SPRING
|
0.0154(lbs); 0.007
|
| 019. |
0401350140
|
[6] |
WASHER PLAIN
|
0.0220(lbs); 0.010
|
| 020. |
3350049030
|
[1] |
WHEEL
|
24.2000(lbs); 11.000
|
| 020. |
3650049030
|
[1] |
WHEEL
|
24.2000(lbs); 11.000
|
| 021. |
3780043750
|
[1] |
TUBE
|
3.3000(lbs); 1.500
|
| 022. |
3780043740
|
[1] |
TIRE
|
32.7800(lbs); 14.900
|
| 023. |
3215027700
|
[1] |
ASSY VALVE
|
0.0022(lbs); 0.001
|
| 024. |
3227011650
|
[1] |
CORE VALVE
|
0.0044(lbs); 0.002
|
| 025. |
3215027740
|
[1] |
CAP
|
0.0066(lbs); 0.003
|
| 026. |
6373317250
|
[2] |
BOLT WHEEL HUB SET
|
0.1760(lbs); 0.080
|
| 027. |
6351217230
|
[2] |
SPRING SET BOLT
|
0.0308(lbs); 0.014
|
| 028. |
6662117160
|
[2] |
PIN AXLE
|
0.1100(lbs); 0.050
|
| 029. |
6213117290
|
[2] |
PIN SNAP
|
0.0088(lbs); 0.004
|
| 040. |
0107351435
|
[6] |
BOLT
|
0.1386(lbs); 0.063
|
