神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (05-003) - MTG. ENGINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
118 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N7709F1 | [1] | MTG, ENGINE | |
| 1. | 2416P14391 | [1] | BRACKET | KOBBRACKET |
| 2. | 2416P18178 | [1] | BRACKET | KOBBRACKET |
| 3. | 2416R235D1 | [4] | RUBBER SLEEVE | KOBMOUNT |
| 4. | 2416R145D2 | [4] | RUBBER SLEEVE | KOBMOUNT |
| 5. | ZS13C10030 | [16] | SCREW | KOBM10x1.50x30mm Superseded by part number: ZS18C10030 |
| 6. | ZW22X10000 | [16] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 7. | 2414T1512 | [8] | COVER | KOB |
| 8. | ZS13C18120 | [4] | CAPSCREW M18x2.0x120mm | CAPSCREW M18x2.0x120mm |
| 9. | ZN13C18015 | [4] | NUT | KOBM18x2.5mm |
| 10. | 2418T17441D2 | [8] | WASHER | KOB |
| 11. | 2416N5981 | [1] | BRACKET | KOBBRACKET |
| 12. | 2416P18181 | [1] | BRACKET | KOBBRACKET |
