神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (06-001) - WIRING ASSY. ELEC Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
425 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J15145F2 | [1] | WIRING ASSY, ELEC | |
| 2. | 24101J459 | [1] | SCHEMATIC, ELEC (NOT SERVICE) | |
| 3. | 2479R1470F1 | [1] | RELAY,24V, 100 Amp | KOBBATTERY |
| 4. | 2479U1009F1 | [1] | HORN,24V, 390HZ | KOBHigh (415Hz) Superseded by part number: CM53S00002F1 |
| 5. | 2479U1009F2 | [1] | HORN,24V, 350HZ | KOBLow (390Hz) Superseded by part number: CM53S00002F2 |
| 7. | 2486R87D2 | [1] | CABLE | KOBBATTERY |
| 8. | 2486R88D3 | [1] | ELECTRIC CABLE | KOB |
| 9. | 2486Z139D1 | [1] | CABLE | KOBBATTERY |
| 10. | 2486R90D2 | [1] | ELECTRIC CABLE | KOBBATTERY |
| 11. | 2479U1652 | [1] | WIRE HARNESS | KOB |
| 12. | 2479U1577 | [1] | WIRE HARNESS | KOB |
| 13. | 2479U1649 | [1] | WIRE HARNESS | KOB |
| 14. | 2479Z2427 | [1] | HARNESS | KOB |
| 16. | 2479Z1918D2 | [1] | HARNESS | KOB |
| 23. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 24. | ZS31C06010 | [1] | SCREW,Phillips Drive, Pan HD, M6 x 10mm | KOBM06x1.0x10mm |
| 25. | ZN18C06005 | [2] | NUT | KOBM06x1.0mm |
| 26. | ZW26X06000 | [3] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 27. | ZW16K06000 | [3] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 28. | ZS18C08025 | [4] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 29. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 30. | ZW26X08000 | [7] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 31. | ZW16K08000 | [5] | WASHER,8mm ID x 15.5mm OD x 1.6mm Thk | KOBID 08 x OD 15.5 x Th 1.6mm |
| 32. | ZS18C10014 | [3] | SCREW,Hex, M10 x 14mm | KOBM10x1.50x14mm |
| 33. | ZN18C10008 | [3] | NUT | KOBM10x1.50mm |
| 34. | ZW26X10000 | [5] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 35. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 37. | 2432Z290 | [10] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 38. | 2432R233D3 | [2] | CLIP | KOB50x16x60mm |
