神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (07-008) - INSTAL. CRAWLER TRACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
679 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J12026F6 | [1] | INSTAL, CRAWLER TRACK | |
| 2. | 2424N196D1 | [98] | SHOE,600mm Triple Grouser | KOB |
| 7. | 2420T6976 | [392] | BOLT,Spher Hex, M20 x 1.5 x 56.50mm, Cl 2 | KOBM20x1.50x56.5mm Superseded by part number: 47796204 |
| 8. | 2420P1552 | [392] | NUT,M20, 1.5mm Pitch, HT | KOBM20x1.50mm Superseded by part number: 2420P1584 |
| 11. | 24100J12027F2 | [2] | CHAIN | KOBTRACK LINK ASSY |
| 11-1. | 2424J171D1 | [48] | CHAIN LINK | KOBR.H. |
| 11-2. | 2424J171D2 | [48] | TRACK LINK | KOB Superseded by part number: 2424J377 |
| 11-3. | 2424N201D1 | [1] | CONNECTING LINK | KOBMASTER, R.H. |
| 11-4. | 2424N201D2 | [1] | CONNECTING LINK | KOBMASTER, L.H. |
| 11-5. | 2405P693 | [48] | BUSHING, TRACK | BUSHING, TRACK |
| 11-6. | 2419T6091 | [48] | PIN,36.66mm OD x 206.4mm L | KOBTRACK |
| 11-7. | 2405P394 | [1] | BUSHING | KOB Superseded by part number: 2405P392 |
| 11-8. | 2419T6092 | [1] | PIN | KOBMASTER |
| 11-9. | 2418T19915 | [2] | COLLAR CLAMP | KOB |
| 11-10. | 2419Z214 | [1] | WIRE | KOBSPLIT |
| 11-11. | 2445Z1449 | [96] | SEAL,40mm ID x 59.8mm OD x 5.7mm Thk | KOB |
| . . | 24100J12026F7 | [1] | INSTAL, CRAWLER TRACK CONISTS OF ITEM 7, 8, & 11 | |
| 3. | 2424N196D2 | [98] | SHOE,700mm Triple Grouser | KOB |
| . . | 24100J12026F8 | [1] | INSTAL, TRACK, CRAWL CONSISTS OF ITEM 7, 8 & 11 | INSTAL, TRACK, CRAWL CONSISTS OF ITEM 7, 8 & 11 |
| 4. | 2424N196D3 | [98] | SHOE,800mm Triple Grouser | KOBSHOE |
| . . | 24100J12026F9 | [1] | INSTAL, CRAWLER TRACK CONSISTS OF ITEM 8 & 11 | |
| 5. | 2424N205 | [98] | SHOE | KOBBOLT |
| 9. | 2420T7262D1 | [392] | BOLT | KOBSHOE |
| . . | 24100J12026F10 | [1] | INSTAL, TRACK, CRAWL CONSISTS OF ITEM 8 & 11 | INSTAL, TRACK, CRAWL CONSISTS OF ITEM 8 & 11 |
| 6. | 2424N204 | [98] | SHOE | KOB Superseded by part number: YN60D00057P1 |
| 10. | 2420T7262D2 | [392] | SCREW | KOBSHOE |
