神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (12-004) - VALVE ASSY. PORT RELIEF Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
400 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R768F1~F5 | [1] | VALVE ASSY, PORT RELIEF CONSISTS OF THE FOLLOWING PARTS | |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONBODY F2, F3, F4, F5 |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT F2, F3, F4, F5 |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER F2, F3, F4, F5 |
| 13. | 2436R819S521 | [1] | SPRING | KOBF2, F3, F4, F5 |
| 14. | 2436R819S163 | [1] | O-RING | KOBF2, F3, F4, F5 Superseded by part number: 2436R837S163 |
| 15. | ZD85P00700 | [1] | BACK-UP RING | KOBID 07 x OD 10 x Th 1.25mm, F2, F3, F4, F5 |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBODY F1 |
| 161. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 162. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 163. | ZD12P01000 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm, F1 |
| 164. | ZD85P01000 | [1] | RING, SNAP | KOBSNAP RING BACK UP F1 |
| 201. | 2436R683S201 | [1] | PLUG | KOB |
| 261. | ZD12P02200 | [1] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm |
| 511. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER F1 |
| 521. | 2436R683S521 | [1] | SPRING | KOBF1 |
| 522. | 2436R683S522 | [1] | SPRING | KOB |
| 541. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT |
| 611. | 2436R682S401 | [1] | POPPET | KOB |
| 612. | 2436R682S521 | [1] | SEAT | KOBSPRING |
| 613. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 614. | 2436R750S614 | [1] | SEAT, SPRING F1 | |
| 621. | 2436R683S1 | [1] | SPRING | KOB |
| 641. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT F1 |
| 651. | 2436R683S651 | [1] | SET SCREW | KOBADJUSTING |
| 663. | ZD12P00600 | [1] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm |
| 671. | 2436R683S671 | [1] | NUT | KOB Superseded by part number: ZN18C12007 |
| 691. | NSS | [1] | NOT SOLD SEPARAT | CONFILTER |
