神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (12-003) - VALVE ASSY. RELIEF - 2436R685F1-F4 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
624 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R685F1~F4 | [1] | VALVE ASSY, RELIEF CONSISTS OF THE FOLLOWING PARTS | |
| l. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET F2 |
| 2. | 2436R685S2 | [1] | SPRING F2 | |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONROD F2, F3, F4 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET F3 |
| 5. | 2436R685S5 | [1] | SPRING | KOBF3 |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET F4 |
| 7. | 2436R685S7 | [1] | SPRING F4 | |
| 551. | 2436U1165S551 | [1] | PLUG | KOB |
| 561. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 611. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET F1 |
| 621. | 2436R685S621 | [1] | SPRING F1 | SPRING F1 |
| 631. | NSS | [1] | NOT SOLD SEPARAT | CONROD F1 |
| 632. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 638. | NSS | [1] | NOT SOLD SEPARAT | CONSCREEN |
