神钢零件查询(MD200C) - EXCAVATOR BTW YQU0701 - YQU2000 (1/80-12/06) (12-006) - VALVE ASSY. SEQUENCE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
729 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U2585F1 | [1] | VALVE PRESSURE RELIE | KOBASSY, SEQUENCE CONSISTS OF THE FOLLOWING PARTS |
| 266. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 267. | ZD12P01090 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 14mm |
| 308. | 2436U2585S308 | [1] | SPOOL | KOB |
| 309. | 2436U1231S309 | [1] | PISTON & RINGS KIT | KOB |
| 344. | 2436U2585S344 | [1] | SLEEVE | KOB |
| 346. | 2436U1231S346 | [1] | BUSHING | KOB |
| 347. | 2436U1231S347 | [1] | STOPPER | |
| 356. | 2436U2585S356 | [1] | PLUG | |
| 375. | 2436U2585S375 | [1] | SPRING | KOB |
| 376. | 2436U1231S376 | [1] | SEAT SPRING N/A | SEAT SPRING N/A |
