凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (35.359.13) - VALVE BOX DOOR, DOUBLE AND TRIPLE BIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
720 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87268843
|
[1] |
DOOR
|
BN
Valve Box, Control Node Compartment, Double and Triple Bin Superseded by part number: BN50697, BN50138, 87266738, 87266728, 113-2299, 87266734, 87268842, BN55359, 87270007, 87266729
|
| 2. |
87268865
|
[2] |
RETAINER COLLAR
|
BN
Hinge Door
|
| 3. |
87271165
|
[1] |
CABLE,713mm L
|
BN
Breakaway, 28"
|
| 4. |
BN50232
|
[2] |
BOLT,5/16"-18 x 1.00", Stainless Steel
|
BN
|
| 5. |
BN50948
|
[1] |
BOLT,Hex, 3/8" - 16 x 2 1/2", Stainless
|
BN
3/8-16 X 2-1/2", Stainless Steel
|
| 6. |
BN55361
|
[2] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 7. |
BN23452
|
[3] |
WASHER,13/32" x 1.25 " OD x 12 GA, SS
|
BN
|
| 8. |
87265700
|
[1] |
BUSHING
|
BN
Door Retainer
|
| 9. |
BN50759
|
[2] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 10. |
BN50260
|
[1] |
BOLT,3/8"-16 x 1-1/2", Stainless Steel
|
CUR
Superseded by part number: 113-2234
|
| 11. |
BN50146
|
[1] |
WASHER,3/8", Stainless
|
BN
|
| 12. |
BN50064
|
[1] |
NUT
|
BN
3/8"-16, Stainless Steel Superseded by part number: 14090608
|
