凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (35.359.14) - VALVE BOX DOOR ASSEMBLY, DOUBLE AND TRIPLE BIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
262 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87268842
|
[1] |
DOOR PANEL
|
TYR
Valve Box Door
|
| 2. |
87266734
|
[1] |
COVER
|
TYR
Front
|
| 3. |
87266738
|
[2] |
PLATE
|
BN
Wire Seal
|
| 4. |
BN50697
|
[4] |
BOLT,Hex, 1/4" - 20 x 1/2", SST
|
BN
|
| 5. |
BN50250
|
[5] |
BOLT,3/8"-16 x 3/4", Stainless Steel
|
BN
Superseded by part number: 113-2299
|
| 6. |
BN55359
|
[4] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 7. |
BN50138
|
[2] |
WASHER,1/4", SS
|
BN
|
| 8. |
87266729
|
[1] |
GROMMET
|
BN
3/4" ID
|
| 9. |
87266728
|
[1] |
GROMMET
|
BN
1-1/2", ID
|
| 10. |
87270007
|
[1] |
DECAL
|
BN
Solenoid and Valve Configuration, Hydraulic Box
|
