神钢零件查询(MD240BLC) - EXCAVATOR ASN LL1488 (1/80-12/06) (02-006) - COVER ASSY, UNDER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
324 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6588F5 | [1] | COVER ASSY,UNDER | |
| 1. | 2414P6004 | [1] | COVER | KOB |
| 4. | 2414P6038 | [1] | COVER | KOB |
| 5. | 2414T2687 | [1] | COVER | KOB |
| 13. | 2414P6098 | [1] | COVER | KOB |
| 14. | 2414P6099 | [1] | COVER | KOB |
| 15. | 2414P6100 | [1] | COVER | KOB |
| 17. | 2414P6752 | [1] | COVER | KOB |
| 18. | 2420T6787 | [34] | SCREW,M12 x 1.75 x 20mm | KOBM12x1.75x20mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12030 |
| 19. | 2420T6788 | [4] | SCREW,M10 x 1.5 x 25mm | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C10025 |
