神钢零件查询(MD240BLC) - EXCAVATOR ASN LL1488 (1/80-12/06) (11-020) - CYLINDER ASSY (ARM) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
557 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U953F1 | [1] | CYLINDER | KOBASSY, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2438U953S1 | [1] | BARREL | KOB |
| 2. | 2438U953S2 | [1] | PISTON ROD | KOB |
| 3. | 2438U953S3 | [1] | CYLINDER HEAD | KOB |
| 4. | 2438U953S4 | [1] | BUSHING | KOB |
| 5. | 2438U953S5 | [1] | SNAP RING | KOB |
| 6. | 2438U953S6 | [1] | RUBBER BLOCK | KOBBUFFER |
| 7. | 2438U953S7 | [1] | SNAP RING | KOB |
| 8. | 2438U953S8 | [1] | BACK-UP RING | KOB |
| 9. | 2438U953S9 | [1] | RING | KOBSLIDING |
| 10. | 2438U953S10 | [1] | WIPER BLADE | KOB Superseded by part number: YN01V00020S009 |
| 11. | ZD12P14000 | [1] | O-RING | KOB |
| 12. | 2438U1324S11 | [1] | BACK-UP RING | KOB |
| 13. | ZS23C24080 | [8] | SCREW | KOBM24x3.0x80mm |
| 14. | 2438U953S14 | [1] | BUSHING | KOBCUSHION |
| 15. | 2438U953S15 | [1] | PISTON | KOB |
| 16. | 2438U1324S15 | [1] | SEALING RING | KOB |
| 17. | 2438U953S17 | [2] | RING | KOBSLIDING |
| 18. | 2438U1324S17 | [2] | RING | KOBSLIDING |
| 19. | 2438U953S19 | [1] | SHIM | KOB |
| 20. | 2438U953S20 | [1] | NUT | KOB |
| 21. | 2438U953S21 | [1] | SET SCREW | KOB |
| 22. | 2436U799S6 | [1] | BALL | KOB |
| 23. | 2438U1324S22 | [2] | BUSHING | KOB |
| 24. | 2438U1381S24 | [4] | SCRAPER RING | KOB |
| 25. | 2438U953S25 | [1] | BAND | KOB |
| 26. | 2438U953S26 | [1] | BAND | KOB |
| 27. | 2438U999S29 | [2] | SCREW | KOB Superseded by part number: ZS18C10035 |
| 28. | 2438U999S30 | [2] | LOCK WASHER | KOB Superseded by part number: ZW26X10000 |
| . . | 2438U953R100 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 6 - 12 Superseded by part number: 2438U1137R100 |
| . . | 2438U953R200 | [1] | REPAIR KIT | KOBREPAIR KIT, CONSISTS OF REF. 16 - 18 Superseded by part number: 2438U1137R400 |
