| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4070F3 | [1] | HEATER ASSY | |
| 1. | 2479U293D3 | [1] | HEAT EXCHANGER | KOB Superseded by part number: 2479U293D4 |
| 2. | R44T0180 | [1] | COCK | KOB |
| 4. | R18T0026D2 | [1] | HOSE,12mm ID x 2700mm L | KOBID 12 x OD 22 x 2700mm |
| 5. | R18T0026D35 | [1] | HOSE | KOBID 12 x OD 22 x 3000mm |
| 6. | 2420Z699 | [1] | GROMMET | KOB |
| 3. | ZC15X02300 | [4] | CLIP | KOB |
| 9. | 2432Z290 | [3] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 10. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 11. | ZW16X10000 | [5] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 12. | ZW26X10000 | [5] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 13. | 2414Z199D025 | [1] | PROTECTIVE SLEEVE | KOBHose -- 250mm Long (9-27/32 in) |
| 14. | ZC47X22014 | [1] | CLIP | KOBCLIP Superseded by part number: ZC48X22014 |
| 15. | ZC45X22011 | [1] | CLIP | KOBClamp -- Ø22mm Single Cable Superseded by part number: ZC46X22011 |
| 16. | ZN16C10008 | [1] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 17. | R44T0183 | [1] | HYD CONNECTOR | KOB |
| 18. | 2479Z1817 | [1] | WIRE HARNESS | KOB |
