凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (39.130.27) - VENTURI GROUP, RH, 2-1/2" TUBES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
542 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86986582
|
[1] |
VENTURI
|
BN
Complete, RH, 2-1/2" Boom Tubes, 3" Rear Tubes, Includes Ref 2 - 8
|
| 2. |
BN300323
|
[2] |
VENTURI
|
BN
2-1/2" OD x 1" ID, Blue
|
| 3. |
BN300324
|
[5] |
VENTURI
|
BN
2-1/2" OD x 1.1" ID, Red
|
| 4. |
BN300325
|
[1] |
VENTURI
|
BN
2-1/2" OD x 1.2" ID, Green
|
| 5. |
BN55388
|
[10] |
SCREW,#10 x 3/8", SST
|
BN
#10 X 3/8, Stainless Steel, Type A
|
| 6. |
86986576
|
[1] |
VENTURI
|
BN
RH, 2.5" Boom Tubes With 3" Rear Tubes
|
| 7. |
BN303566
|
[1] |
VENTURI
|
BN
3" OD x 1.4" ID, Brown
|
| 8. |
BN303565
|
[1] |
VENTURI
|
BN
3" OD x 1.3" ID, Yellow
|
