凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (55.100.13) - REMOTE MODULE HARNESS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
391 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87266537
|
[1] |
HARNESS
|
BN
Remote Module, Includes Ref 2 - 8
|
| 2. |
245482C1
|
[1] |
ELEC CONNECTOR,2 Pin
|
IH
Remote Park Brake, X-630F Superseded by part number: 87692855
|
| 3. |
245487C1
|
[1] |
ELEC CONNECTOR,Male, 4 Pin
|
IH
Remote Controller Input, X-517M Superseded by part number: 87692802
|
| 4. |
245486C1
|
[1] |
ELEC CONNECTOR,4 Pin
|
IH
Remote Controller Output, X-520F Superseded by part number: 87692817
|
| 5. |
225319C1
|
[1] |
MULTIPOLE CONNECTOR,Female, 8 Pin
|
CAS
Engine, X-800F Superseded by part number: 87700325
|
| 6. |
222136A1
|
[1] |
ELEC CONNECTOR,Male, 2 Pin
|
CAS
Light, X-006 Superseded by part number: 87696547
|
| 7. |
1964702C1
|
[16] |
TERMINAL CONNECTOR
|
CAS
#6 Rings
|
| 8. |
1964703C1
|
[2] |
TERMINAL CONNECTOR
|
CAS
#8 Rings
|
