凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (55.404.01) - METERING/CO-AP LIGHT ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
803 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN310648
|
[1] |
LIGHT
|
BN
Metering Frame and Co-Ap Boxes, Complete, Includes Ref 2 -6
|
| 2. |
BN310671
|
[1] |
LAMP
|
BN
Clear, Sealed
|
| 3. |
BN310672
|
[1] |
GROMMET
|
BN
Snap Lock
|
| 4. |
BN310673
|
[1] |
WIRE HARNESS
|
BN
6" Long, Does Not Include Ref 4
|
| 5. |
87692855
|
[1] |
CONTACT HOUSING,Male, 2 Cavities
|
BN
Co-Ap Box Light
|
| 5. |
225123C1
|
[2] |
TERMINAL CONNECTOR,Tin, 0.8mm
|
IH
Co-Ap Box Light
|
| 5. |
BN16056
|
[2] |
SEAL
|
BN
Co-Ap Box Light Superseded by part number: 84286327
|
| 6. |
BN54139
|
[1] |
GROMMET
|
BN
Rubber, 1/4" ID x 1" OD
|
