凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (55.100.19) - TRANSMISSION SHIFTER HARNESS ADAPTER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
241 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87270254
|
[1] |
WIRE HARNESS
|
BN
Adapter, No Auxiliary Transmission, Includes Ref 2 - 4
|
| 2. |
225389C1
|
[1] |
CONNECTOR, ELEC
|
IH
CONNECTOR P126 Superseded by part number: 87695592
|
| 2. |
87695651
|
[1] |
LOCKING TAB,Wedge Lock
|
BN
P126
|
| 2. |
87695921
|
[10] |
CONTACT,Female, Nickel, 0.50 - 1.00mm
|
COE
P126
|
| 3. |
225388C1
|
[1] |
ELEC CONNECTOR,Male, 12 Pin
|
IH
J126 Superseded by part number: 87695724
|
| 3. |
87698541
|
[1] |
LOCKING TAB,Wedge Lock, 12-Pin
|
ZED
J126
|
| 3. |
381417A1
|
[10] |
TERMINAL,Male, Nickel, 0.50 - 1.00mm
|
CAS
J126 Superseded by part number: 87695623
|
