神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (17-051) - EXHAUST PIPE - 250-400B Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
601 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | VAME039715 | [2] | U-BOLT | KOB |
| 3. | VAMF434104 | [8] | NUT | KOBNUT, FLANGE 8 |
| 4. | VAME037801 | [1] | BRACKET MUFFLER | BRACKET MUFFLER |
| 4A. | VAME047846 | [1] | SUPPORT, MUFFLER BRACKET | |
| 5. | VAMH000148 | [4] | SCREW | KOBBOLT, W/WSR 10X30 |
| 6. | VAMH000706 | [1] | SCREW | KOBBOLT, FLANGE 10X16 Superseded by part number: 132289A1 |
| . . | VAMH000723 | [1] | BOLT | KOBBOLT, FLANGE 10X70 |
| 6A. | VAMF244876 | [2] | BOLT, W/WSR 10X16 | |
| 8. | VAME070503 | [1] | PIPE | KOB Superseded by part number: VAME078469 |
| 9. | VAME034997 | [1] | SEAL RETAINER | KOB Superseded by part number: VAME170410 |
| 9A. | VAME034998 | [1] | PISTON RING SET | KOB |
| 10. | VAME070508 | [1] | BRACKET | KOB |
| 11. | VAMH000676 | [2] | SCREW | KOBBOLT 10X20 |
| 12. | VAMF140221 | [2] | BOLT | KOBBOLT, FLANGE 8X12 |
| 13-15. | VAME068372 | [1] | CLAMP | KOB |
| 13. | VAME068373 | [1] | CLAMP | KOB Superseded by part number: VAME068372 |
| 15. | VAMF101314 | [2] | SCREW | KOBBOLT 12X35 Superseded by part number: VAF103512035 |
| . . | VAMS446185 | [2] | NUT | KOBNUT, FLANGE 12 |
