神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (17-050) - INSTRUMENT - 090-200C Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
384 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | VAMH052231 | [2] | HYD CONNECTOR | KOBCONNECTOR, 2P FEMALE |
| 2B. | VAMH052064 | [1] | TERMINAL | KOBCONNECTOR |
| 2G. | VAMH052327 | [1] | HYD CONNECTOR | KOBCONNECTOR, 6P FEMALE |
| 2R. | VAMH052377 | [1] | HYD CONNECTOR | KOBCONNECTOR, 1P FEMALE |
| 2S. | VAMH052356 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 2T. | VAMB286874 | [1] | HYD CONNECTOR | KOBCONNECTOR ASSY, 2P FEMALE |
| 3. | VA3096803122 | [1] | GROMMET | KOBGROMMET |
| 3A. | VAMH022419 | [1] | GROMMET | KOBGROMMET |
| 8C. | VAME049233 | [1] | RELAY | KOBEngine Part number Superseded by part number: ME049233 |
