神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (03-003) - REWORK, REMOTE-CONTROL (24100N7070F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
362 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | 2436R732F1 | [1] | SOLENOID VALVE | KOBSee Figure 16-002 |
| 4. | 2416P14902 | [1] | BRACKET | BRACKET |
| 6. | 2420R537D050 | [2] | HOSE,9.53mm ID x 500mm L | KOBUsed from date 06/25/1990 - 11/08/1993 |
| . . | 2420R1183D050 | [2] | FLEXIBLE HOSE | KOBHOSE Used from date 11/08/1993 - 01/09/1995 Superseded by part number: 2420R537D050 |
| . . | HX21E06050DX | [2] | FLEXIBLE HOSE | KOB500mm Long (19-11/16 in) -- Used after date 01/09/1995 Superseded by part number: 2420R537D050 |
| 7. | 2479Z2441 | [1] | HARNESS | KOBUsed before date 04/23/1991 |
| . . | 2479Z2744 | [1] | HARNESS | KOBUsed after date 04/23/1991 |
| 8. | ZH22X06000 | [4] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of ZH22X06000), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| 10. | ZS23C06020 | [2] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm Superseded by part number: ZS28C06020 |
| 11. | ZS13C10025 | [2] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 12. | ZN13C06005 | [2] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 13. | ZN13C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 14. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 15. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
