神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (15-002) - CYLINDER ASSY (L.H. BOOM) - 243U1136F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
414 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1136F1 | [1] | CYLINDER | KOBASSY, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U1135F1 |
| 1. | 2438U999S1 | [1] | HYDRAULIC CYLINDER | KOB |
| 2. | 2438U1135S2 | [1] | PISTON ROD | KOB |
| 3. | 2438U999S3 | [1] | AIR CONDITIONER | KOB |
| 4. | 2438U999S4 | [1] | BUSHING | KOB |
| 5. | 2438U999S5 | [1] | RING | KOB |
| 6. | 2438U999S6 | [1] | BACK-UP RING | KOBBUFFER |
| 7. | 2438U999S7 | [1] | RING | KOB |
| 8. | 2438U999S8 | [1] | RING | KOB |
| 9. | 2438U999S9 | [1] | RING | KOB |
| 10. | 2438U999S10 | [1] | SEAL | KOB Superseded by part number: 2438U1135S35 |
| 11. | ZD12P13000 | [1] | O-RING | KOB |
| 12. | 2438U999S12 | [1] | BACK-UP RING | KOB |
| 13. | 2438U999S13 | [8] | SCREW | KOBBOLT |
| 14. | 2438U1135S14 | [1] | BEARING CUP | KOB |
| 15. | 2438U1135S15 | [1] | OIL SEAL | KOBCUSHION |
| 16. | 2438U999S15 | [1] | PISTON | KOB |
| 17. | 2438U999S16 | [1] | RING | KOB |
| 18. | 2438U999S17 | [2] | RING | KOB |
| 19. | 2438U999S18 | [2] | RING | KOB |
| 20. | 2438U999S19 | [1] | SHIM | KOB |
| 21. | 2438U999S20 | [1] | NUT | KOB |
| 22. | 2438U999S21 | [1] | SET SCREW | KOBSet -- M12x1.75mm |
| 23. | 2436U330S16 | [1] | BALL | KOB |
| 24. | 2438U999S23 | [1] | BUSHING | KOB |
| 25. | 2438U999S25 | [1] | BUSHING | KOB |
| 26. | 2438U999S26 | [2] | SEAL | KOB |
| 27. | 2438U1135S27 | [1] | BAND | KOBBRACKET |
| 28. | 2438U999S28 | [1] | BAND | KOBBRACKET |
| 29. | 2438U999S29 | [2] | SCREW | KOB Superseded by part number: ZS18C10035 |
| 30. | 2438U999S30 | [2] | LOCK WASHER | KOB Superseded by part number: ZW26X10000 |
| 31. | 2438U1381S24 | [2] | SCRAPER RING | KOB |
| 32. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| . . | 2438U999R100 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 6 - 12 Superseded by part number: 2438U1135R100 |
| . . | 2438U999R200 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 17 - 19 Superseded by part number: 2438U999R200P |
| . . | 2438U1135R300 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 6-12, 17 - 19 Superseded by part number: 2438U1135R200 |
