神钢零件查询(MD240C) - EXCAVATOR BTW LLU0301 - LLU0600 (1/80-12/06) (15-003) - CYLINDER ASSY (ARM) - 2438U1137F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
522 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1137F1 | [1] | CYLINDER | KOBASSY (ARM), CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U1137F2 |
| 1. | 2438U1137S1 | [1] | BARREL | KOB |
| 2. | 2438U1137S2 | [1] | PISTON ROD | KOB |
| 3. | 2438U953S3 | [1] | CYLINDER HEAD | KOB |
| 4. | 2438U953S4 | [1] | BUSHING | KOB |
| 5. | 2438U953S5 | [1] | SNAP RING | KOB |
| 6. | 2438U953S6 | [1] | RUBBER BLOCK | KOBBUFFER |
| 7. | 2438U953S7 | [1] | SNAP RING | KOB |
| 8. | 2438U953S8 | [1] | BACK-UP RING | KOB |
| 9. | 2438U953S9 | [1] | RING | KOB |
| 10. | 2438U953S10 | [1] | WIPER BLADE | KOB Superseded by part number: YN01V00020S009 |
| 11. | ZD12P14000 | [1] | O-RING | KOB |
| 12. | 2438U1324S11 | [1] | BACK-UP RING | KOB |
| 13. | ZS23C24080 | [8] | SCREW | KOBM24x3.0x80mm |
| 14. | 2438U1137S14 | [1] | BEARING CUP | KOB |
| 15. | 2438U1137S15 | [1] | OIL SEAL | KOBCUSHION |
| 16. | 2438U953S15 | [1] | PISTON | KOB |
| 17. | 2438U1324S15 | [1] | SEALING RING | KOB |
| 18. | 2438U953S17 | [2] | RING | KOB |
| 19. | 2438U1324S17 | [2] | RING | KOB |
| 20. | 2438U953S19 | [1] | SHIM | KOB |
| 21. | 2438U953S20 | [1] | NUT | KOB |
| 22. | 2438U953S21 | [1] | SET SCREW | KOB |
| 23. | 2436R624S6 | [1] | BALL | KOB |
| 24. | 2438U1137S24 | [1] | BEARING CUP | KOB |
| 25. | 2438U1137S25 | [1] | OIL SEAL | KOBCUSHION |
| 26. | 2438U1137S26 | [2] | STOP | KOB |
| 27. | 2438U1137S27 | [1] | SNAP RING | KOB |
| 28. | 2438U1324S22 | [2] | BUSHING | KOB |
| 29. | 2438U1137S29 | [1] | U-BRACKET | KOBBRACKET |
| 30. | 2438U1017S26 | [1] | U-BRACKET | KOB Superseded by part number: 2438U1017S28 |
| 31. | 2438U999S29 | [2] | SCREW | KOB Superseded by part number: ZS18C10035 |
| 32. | 2438U999S30 | [2] | LOCK WASHER | KOB Superseded by part number: ZW26X10000 |
| 33. | 2438U1381S24 | [4] | SCRAPER RING | KOB |
| 34. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| . . | 2438U953R100 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 6 - 12 Superseded by part number: 2438U1137R100 |
| . . | 2438U953R200 | [1] | REPAIR KIT | KOBREPAIR KIT, CONSISTS OF REF. 17 - 19 Superseded by part number: 2438U1137R400 |
| . . | 2438U1137R300 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 6 - 12, 17 - 19 Superseded by part number: 2438U1137R200 |
