| . . | 24100J13498F2 | [1] | PANEL ASSY, INST | |
| 1. | 2414J2493 | [1] | STAND | KOB |
| 1-10. | 2405R61D11 | [2] | BUSHING | KOB |
| 2. | 2427N3092 | [1] | PANEL | KOB |
| 3. | 2427P3553 | [1] | PLATE | KOBPANEL INSTRUMENT |
| 4. | 2414P8209 | [1] | COVER | KOB |
| 5. | 2414N4691 | [1] | COVER | KOB |
| 6. | 2414T4945 | [1] | COVER | KOB |
| 7. | 2416T23659 | [1] | BRACKET | KOB |
| 9. | 2418T22758 | [1] | PLATE | KOB |
| 10. | 24100P2721F2 | [1] | LEVER | KOB |
| 10-1. | 2416P14378 | [1] | BRACKET | KOB |
| 10-3. | 2418T17877 | [1] | WASHER | KOB |
| 10-4. | R16T0137D2 | [6] | WASHER | KOBCone Disk Spring -- ID 12.2 x OD 25 x Th 1.6mm |
| 10-5. | R16T0040 | [1] | WASHER | KOB Superseded by part number: 2418T12345, 77266155 |
| 10-6. | ZN32C12011 | [1] | NUT | KOB |
| 10-14. | 2406P4789 | [1] | LEVER | KOB |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONGAUGE, CLUSTER, SEE FIGURE 05-008 |
| 14. | 2480U284F2 | [1] | POTENTIOMETER | KOB |
| 15. | 2480U285F1 | [1] | POTENTIOMETER | KOB |
| 16. | 2421R180F1 | [1] | CIGARETTE LIGHTER | KOB Superseded by part number: YN81S00003P1 |
| 17. | 2480U307F2 | [1] | CONTROL | KOB |
| . . | NSS | [1] | NOT SOLD SEPARAT | CON(GAUGE, CLUSTER) |
| 18. | 2480U332F2 | [1] | CONTROL | KOB |
| 20. | 2479U1281F2 | [1] | FUSE BOX | KOB, Serial Range: LLU00301-LLU00343 Superseded by part number: 2479U1281F5 |
| . . | 2479U1281F4 | [1] | FUSE | KOBBOX, FUSE, Start Serial: LLU00344 Superseded by part number: 2479U1281F5 |
| 20-1. | 2479U717S1 | [1] | BASE | HITLLU00301, Serial Range: -LLU00343 |
| 20-2. | 2479U717S2 | [1] | COVER | KOB, Serial Range: LLU00301-LLU00343 |
| 20-3. | 2479U717S3 | [1] | PULLER | KOBFuse |
| 20-4. | 2479U717S7 | [16] | FUSE | KOB15 Amp |
| 20-5. | 2479R655S10 | [4] | FUSE | KOB5 Amp Superseded by part number: 2479U717S5 |
| 20-8. | 2479U1281S8 | [1] | HARNESS | KOBHARNESS |
| 20-9. | 2479U1281S9 | [1] | LABEL | KOB |
| 20-10. | 2479U1281S10 | [1] | BASE | KOB, Start Serial: LLU00344 |
| 20-11. | 2479U1281S11 | [1] | COVER | KOB, Start Serial: LLU00344 |
| 21. | 2447R135 | [1] | BUZZER | KOB |
| 22. | 2484R166D2 | [1] | RESISTOR,51 Ohm | KOB Superseded by part number: 2484R166D5 |
| 24. | 2479R1366 | [1] | RELAY | KOB |
| 25. | 2479T1424 | [4] | RELAY, Serial Range: LLU00301-LLU00425 | |
| . . | 2479T1424 | [5] | RELAY, Start Serial: LLU00426 | |
| 26. | 2479U1447 | [1] | RELAY,24V, 4 Sec Delay | KOB |
| 27. | 2475R132 | [2] | DIODE,400V, 3 Amp | KOB |
| 28. | 2414T4530 | [4] | CAP | KOBSwitch -- 20x30mm |
| 29. | 2420Z1322 | [1] | GROMMET | KOB |
| 30. | 2420Z1325 | [1] | GROMMET | KOB |
| 31. | 2420Z1342 | [1] | GROMMET | KOB |
| 32. | 2406T3073 | [1] | GRIP | KOBCLIP |
| 33. | 2479U1190F13 | [1] | SWITCH | KOB(HEAVY LIFT) |
| 34. | 2479U1348F2 | [1] | SWITCH | KOB(MODE SELECT) |
| 35. | 2479U1278F2 | [1] | SWITCH | KOB(WIPER) |
| 38. | 2479U1190F7 | [1] | SWITCH | KOB(AUTO ACCELE) |
| 39. | 2479U1191F1 | [1] | SWITCH | KOB(BUZZER STOP) |
| 40. | 2479Z1447 | [1] | SWITCH | KOB(MODE SELECT) |
| 41. | 2479U1190F6 | [1] | SWITCH | KOB(2-SPEED) |
| 42. | 2479U1190F1 | [1] | SWITCH | KOB |
| 43. | 2479U1224F1 | [1] | SWITCH | KOB |
| 44. | 2432T4345 | [1] | LABEL | KOB |
| 46. | 2420Z1323D1 | [4] | SCREW | KOB |
| 47. | 2420R944D2 | [2] | BOLT | KOB |
| 48. | 2420R1087D2 | [4] | SCREW | KOB Superseded by part number: ZM46C06016 |
| 49. | ZM11C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 50. | 2420R944D1 | [3] | BOLT | KOB |
| 51. | 2420R1090D2 | [4] | SCREW,M6 x 16mm | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) Superseded by part number: ZM46C06016 |
| 52. | 2420R1087D1 | [13] | SCREW | KOB, Serial Range: LLU00301-LLU00425 Superseded by part number: ZM46C06012 |
| . . | 2420R1087D1 | [14] | SCREW | KOB, Start Serial: LLU00426 Superseded by part number: ZM46C06012 |
| 53. | 2420R1092D1 | [4] | BOLT,M5 x 35mm | KOBM05x0.8x35mm (Incls. Washer & Lockwasher) |
| 54. | 2420R1088D1 | [1] | BOLT,M4 x 6mm | KOBM04x0.7x06mm (Incls. Washer & Lockwasher) |
| 55. | 2420R579D1 | [2] | SCREW,M4 x 16mm | KOBM04x0.7x16mm (Incls. Washer & Lockwasher) |
| 57. | ZS18C10030 | [5] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 58. | ZW16X10000 | [5] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 59. | ZW26X10000 | [5] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 60. | ZW26X06000 | [4] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 61. | ZW22X04000 | [2] | LOCK WASHER | KOBID 04 x OD 07.6 x Th 1.0mm Superseded by part number: ZW26X04000 |
| 62. | ZN18C06005 | [4] | NUT | KOBM06x1.0mm |
| 63. | 2420Z1352 | [1] | NUT | KOBM10x1.50mm |
| 64. | ZN11C04003 | [2] | NUT | KOBM04x0.7mm Superseded by part number: ZN18C04003 |
| 65. | 2479R1473F1 | [1] | HARNESS | KOB |
| 66. | 2479R1909 | [1] | HARNESS | KOB |
| 67. | 2479U1481 | [1] | HARNESS | KOB, Serial Range: LLU00301-LLU00425 |
| 69. | 2405Z160D3 | [1] | BUSHING | KOB |
| 70. | 2405Z160D4 | [1] | BUSHING | KOB |
| 71. | 2479Z2426 | [1] | SWITCH | KOB |
| 72. | 2432T5130 | [1] | LABEL | |
| 73. | 2432T3992 | [1] | LABEL | KOB |
| 79. | 2479U1559 | [1] | HARNESS | KOB, Start Serial: LLU00426 |
| 8. | VAME049233 | [1] | RELAY | KOBSTARTER Superseded by part number: ME049233 |
