| . . | 24100J13064F1 | [1] | BOOM ASSY 6.02M | BOOM ASSY 6.02M |
| 1. | 2411J4227F1 | [1] | BOOM | BOOM |
| 1-39. | 2405T1262 | [2] | BUSHING | KOB |
| 2. | 2438U1135F1 | [1] | CYLINDER | KOBRH (BOOM) |
| 3. | 2438U1136F1 | [1] | CYLINDER | KOBRL (BOOM) Superseded by part number: 2438U1135F1 |
| 4. | 2438U1137F1 | [1] | CYLINDER | KOB(ARM) Superseded by part number: 2438U1137F2 |
| 5. | 2418P22190 | [1] | RIGID TUBE | KOB |
| 6. | 2418P22526 | [1] | TUBE | KOB |
| 7. | 2418P22527 | [1] | RIGID TUBE | KOB |
| 8. | 2418P22525 | [1] | TUBE | KOB |
| 9. | 2418P22189 | [2] | RIGID TUBE | KOB |
| 10. | 2418P22188 | [1] | RIGID TUBE | KOB |
| 11. | 2418P22218 | [1] | RIGID TUBE | KOB |
| 12. | 2418P22194D1 | [1] | RIGID TUBE | KOB |
| 13. | 2418P22194D2 | [1] | TUBE | KOB |
| 14. | 2418P12376D1 | [1] | RIGID TUBE | KOB |
| 15. | 2418P12376D2 | [1] | RIGID TUBE | KOB |
| 16. | ZX26T12094 | [2] | FLEXIBLE HOSE | KOB Superseded by part number: 2444R1177D2 |
| 17. | 2444R1090D1 | [2] | HOSE | KOB |
| 18. | ZX26T12080 | [2] | FLEXIBLE HOSE | KOBHOSE Superseded by part number: 2444R1177D1 |
| 19. | 2444R1097D1 | [2] | FLEXIBLE HOSE | KOBHOSE Superseded by part number: 2444R1171D1 |
| 20. | ZX26T16080 | [2] | FLEXIBLE HOSE | KOB Superseded by part number: 2444R1175D1 |
| 21. | 2444R1117D325 | [1] | FLEXIBLE HOSE,6.40mm ID x 3250mm L | KOB3250mm Long Superseded by part number: HX21E04325DY |
| 22. | 2444R1117D265 | [1] | FLEXIBLE HOSE,6.40mm ID x 2650mm L | KOB Superseded by part number: HX21E04265DY |
| 23. | 2444R1117D080 | [2] | HOSE,6.4mm ID x 800mm L | KOB |
| 24. | ZF23B28000 | [2] | HYD CONNECTOR | KOB Superseded by part number: 47641651 |
| 25. | ZH22Z04000 | [3] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 27. | ZG91S02000 | [8] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 28. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 29. | 2432T2434 | [6] | CLAMP | KOBDouble Line -- 129x38x15mm (Ø29xØ36mm) |
| 30. | ZC26X28014 | [4] | CLAMP | KOBSingle Line -- 75x37x38mm (Ø28mm) |
| 31. | 2432T2245 | [2] | CLAMP | KOB |
| 32. | 2432T2363 | [1] | CLAMP | KOB Superseded by part number: YN42H01078P1 |
| 33. | ZS13C10020 | [1] | SCREW | KOBM10x1.50x20mm Superseded by part number: ZS18C10020 |
| 34. | ZS13C10070 | [16] | SCREW | KOBM10x1.50x70mm Superseded by part number: ZS18C10070 |
| 35. | ZS13C12055 | [12] | SCREW | KOBM12x1.75x55mm Superseded by part number: ZS18C12055 |
| 36. | ZS13C12065 | [1] | SCREW | KOB Superseded by part number: ZS18C12065 |
| 37. | ZS13C12090 | [8] | SCREW | KOBM12x1.75x90mm Superseded by part number: ZS18C12090 |
| 38. | ZS13C14030 | [2] | SCREW | KOBM14x2.0x30mm Superseded by part number: ZS18C14030 |
| 39. | ZS13C16030 | [2] | SCREW | KOBM16x2.0x30mm |
| 40. | 2420T4004D1 | [1] | SCREW,M16 x 2 x 150mm | KOBM16x2.0x150mm |
| 41. | 2420T4004D3 | [2] | SCREW,M16 x 2 x 160mm | KOBM16x2.0x160mm |
| 42. | 2444R1117D275 | [1] | FLEXIBLE HOSE,6.40mm ID x 2750mm L | KOB2750mm Long (108-1/4 in) Superseded by part number: HX21E04275DY |
| 43. | ZN13C16013 | [6] | NUT | KOBM16x2.0mm |
| 44. | 2420Z1047 | [1] | SLOTTED NUT | KOBM56x5.5mm Castle |
| 45. | ZW22X10000 | [17] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 46. | ZW22X12000 | [21] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 47. | ZW22X14000 | [2] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 48. | ZW22X16000 | [2] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 49. | 2418Z715 | [1] | WASHER | KOBID 58 x OD 105 x Th 9.0mm |
| 50. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 51. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 52. | 2445R372D5 | [2] | DUST CAP | KOB |
| 53. | ZP15D08100 | [1] | SPRING | KOBCotter -- OD 08 x 100mm Long |
| 54. | 2418T17477 | [2] | COLLAR CLAMP | KOB |
| 55. | 2419T4676 | [1] | PIN | KOBOD 100 x 894mm Long Superseded by part number: 2419T7608 |
| 56. | 2419T4680D1 | [1] | PIN | KOB |
| 57. | 2419T4678 | [2] | PIN | KOB Superseded by part number: 2419P3437 |
| 58. | 2419P3418 | [1] | PIN | KOB Superseded by part number: 2419P3398D2 |
| 59. | 2419T4681 | [1] | PIN | KOB Superseded by part number: 2419P3438 |
| 60. | 2420T2747D15 | [1] | SHIM,102mm ID x 200mm OD x 0.9mm Thk | KOBID 102 x OD 200 x Th 0.9mm |
| 61. | B16T0442D38 | [1] | SHIM,205mm OD x 102mm ID x 1.6mm Thk | KOBID 102 x OD 205 x Th 1.6mm |
| 62. | B16T0442D35 | [2] | SHIM,160mm OD x 97mm ID x 1.6mm Thk | KOBID 97 x OD 160 x Th 1.6mm |
| 63. | B16T0442D13 | [3] | SHIM,160mm OD x 92mm ID x 1.2mm Thk | KOBID 92 x OD 160 x Th 1.2mm |
| 64. | B16T0442D14 | [3] | SHIM,160mm OD x 92mm ID x 1.6mm Thk | KOBID 92 x OD 160 x Th 1.6mm |
| 68. | 2416T13056 | [1] | BRACKET | KOB |
| 69. | 2418T12469 | [1] | PLATE | KOB150 x 50 x Th 12mm, 2-Ø16 Holes |
| 70. | 2418T17550 | [2] | PLATE | KOBID 18 x OD 60 x Th 06mm |
| 77. | 2432Z309D1 | [3] | CLAMP | KOB |
