凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.110.13.AA) - PRODUCT PUMP, 2" INLET Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
188 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN68766
|
[1] |
PUMP
|
BN
Product, 2" Inlet, Complete, Includes Ref 1 - 9
|
| 2. |
344031A1
|
[1] |
IMPELLER
|
BN
CW Rotation Superseded by part number: 87610600
|
| 3. |
4194
|
[1] |
RING
|
SAS
Slinger Seal
|
| 4. |
6059
|
[1] |
KEY
|
SAS
Shaft Superseded by part number: 80810
|
| 5. |
BN311826
|
[1] |
SEAL KIT
|
BN
Impeller
|
| 6. |
84270018
|
[4] |
BOLT
|
BN
5/16" - 18 x 7/8"
|
| 7. |
84270010
|
[4] |
BOLT
|
BN
3/8" - 16 x 7/8"
|
| 8. |
4199
|
[1] |
NUT
|
SAS
Impeller
|
| 9. |
84272048
|
[1] |
WASHER
|
BN
Impeller
|
| 10. |
84347727
|
[1] |
HYDRAULIC MOTOR
|
BN
HM1, Product Pump
|
