久保田零件查询T09300 BOOSTER [A] [CA] [SECTION PARTS] ELECTRICAL SYSTEMEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
478 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
9631938010
|
[1] |
ASSY BOOSTER
|
9.2400(lbs); 4.200
|
| 020. |
9631938610
|
[1] |
ASSY HOUSING
|
4.0700(lbs); 1.850
|
| 030. |
9631938620
|
[1] |
BOLT
|
0.2200(lbs); 0.100
|
| 040. |
9631938630
|
[1] |
PIN ROLLER
|
0.0044(lbs); 0.002
|
| 050. |
9631938640
|
[1] |
PLUG
|
0.2200(lbs); 0.100
|
| 060. |
9631938650
|
[1] |
PLUG
|
0.1870(lbs); 0.085
|
| 070. |
9631938660
|
[2] |
SEAT SPRING
|
0.0220(lbs); 0.010
|
| 080. |
9631938670
|
[1] |
SPRING
|
0.0110(lbs); 0.005
|
| 090. |
9631938680
|
[1] |
NUT LOCK
|
0.0000(lbs); 0.000
|
| 100. |
9631938690
|
[1] |
YOKE
|
0.1760(lbs); 0.080
|
| 110. |
9631938710
|
[1] |
COVER DUST
|
0.0044(lbs); 0.002
|
| 120. |
9631938720
|
[1] |
PLUNGER
|
0.0000(lbs); 0.000
|
| 130. |
9631938730
|
[1] |
SPRING
|
0.0000(lbs); 0.000
|
| 140. |
9631938740
|
[1] |
ASSY ADJUSTER
|
0.0110(lbs); 0.005
|
| 150. |
9631938750
|
[1] |
ASSY CYLINDER
|
2.4860(lbs); 1.130
|
| 160. |
9631938760
|
[1] |
ROD
|
0.9900(lbs); 0.450
|
| 170. |
9631938770
|
[1] |
PISTON
|
0.0990(lbs); 0.045
|
| 180. |
9631938780
|
[1] |
NUT
|
0.0330(lbs); 0.015
|
| 190. |
9631938790
|
[1] |
ASSY BOX
|
0.4840(lbs); 0.220
|
| 200. |
9631938810
|
[1] |
RING SNAP
|
0.0044(lbs); 0.002
|
| 210. |
9631938830
|
[4] |
BOLT SOCKET HEAD
|
0.0330(lbs); 0.015
|
| 220. |
0451250080
|
[4] |
WASHER SPRING
|
0.0044(lbs); 0.002
|
| 230. |
9631938820
|
[1] |
ORIFICE
|
0.0022(lbs); 0.001
|
| 240. |
9631938840
|
[1] |
SEAT
|
0.0110(lbs); 0.005
|
| 250. |
9631938850
|
[1] |
COVER DUST
|
0.0220(lbs); 0.010
|
| 260. |
0481150250
|
[1] |
RING
|
0.0022(lbs); 0.001
|
| 270. |
9631938900
|
[1] |
KIT SEAL
|
0.0286(lbs); 0.013
|
| 280. |
9631938910
|
[1] |
U-RING
|
0.0022(lbs); 0.001
|
| 290. |
0481110260
|
[2] |
RING
|
0.0022(lbs); 0.001
|
| 300. |
0481150250
|
[2] |
RING
|
0.0022(lbs); 0.001
|
| 310. |
0481110080
|
[2] |
RING
|
0.0022(lbs); 0.001
|
| 320. |
0481107230
|
[1] |
RING
|
0.0022(lbs); 0.001
|
| 330. |
9631938920
|
[1] |
SEAL
|
0.0044(lbs); 0.002
|
| 340. |
9631938930
|
[1] |
U-RING
|
0.0022(lbs); 0.001
|
| 350. |
9631938940
|
[1] |
SEAL DUST
|
0.0220(lbs); 0.010
|
| 360. |
9631938860
|
[1] |
U-RING
|
0.0110(lbs); 0.005
|
