神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (03-001) - CONTROL ASSY, WRIST Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
456 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J8528F5 | [1] | CONTROL ASSY, WRIST | |
| 2. | 24100U157F1 | [1] | TANK | KOB Superseded by part number: YT54C00003F1 |
| 3. | ZS18C10030 | [12] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 4. | ZW26X10000 | [20] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 6. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 10. | 2419T5127 | [1] | PIN | KOB |
| 1 1. | 2414Z270D2 | [1] | CAP | KOB |
| 17. | 2432Z327 | [1] | PLATE | KOB |
| 18. | 2420N458D10040 | [4] | CAPSCREW,Hex Socket Head, M10 x 40mm | KOBSCREW Superseded by part number: ZS28C10040 |
| 21. | 2414P3934 | [1] | COVER | KOB |
| 22. | 2427Z560 | [2] | COVER | KOB |
| 23. | ZW26X06000 | [7] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 24. | 2414N1938 | [1] | COVER | KOB |
| 25. | 2416P8600 | [1] | SUPPORT | |
| 27. | 2416R231 | [1] | GRILLE | KOB |
| 28. | 2420Z1040 | [4] | SCREW | KOB |
| 31. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
| 32. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 34. | 2420T4505 | [18] | WASHER,7mm ID x 16mm OD x 1mm Thk | KOBID 07 x OD 16 x Th 1.0mm |
| 35. | 2418T17297 | [18] | SCREW | KOB |
| 37. | ZS18C08020 | [4] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 39. | 2418T15636 | [18] | LOCK WASHER | KOB |
| 45. | ZS18C06016 | [7] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 46. | 24100N3035F2 | [1] | LEVER ASSY | LEVER ASSY |
| 46-1. | 2416N3254 | [1] | BRACKET | KOB |
| 46-2. | 2406P2591 | [1] | LEVER | LEVER |
| 46-3. | 2414Z270D1 | [1] | CAP | KOBGRIP |
| 46-4. | ZP45X12080 | [1] | PIN | PIN |
| 46-5. | ZW16X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 46-6. | ZP15D04022 | [1] | COTTER PIN | KOBPin, Cotter |
| 46-7. | ZS18C12030 | [1] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 46-8. | 2406T1812 | [1] | BAR | KOB |
| 46-10. | 2479Z954 | [1] | SWITCH | KOB |
| 46-11. | ZN17C12010 | [1] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 46-12. | ZW11K08000 | [1] | WASHER | KOB |
| 46-13. | 2417T513 | [1] | SPRING | SPRING |
| 47. | ZW16X06000 | [5] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 48. | 2420Z1188 | [2] | GROMMET | KOB |
| 49. | 2416N3257 | [1] | STAND | STAND |
| 50. | 2416N3258 | [1] | STAND | KOB |
| 51. | 2414N1955 | [1] | COVER | KOB |
| 52. | 2414N1956 | [1] | COVER | COVER |
| 53. | 2414N1957 | [1] | COVER | KOB |
| 54. | 2414N1958 | [1] | COVER | KOB |
| 55. | 2416R233 | [1] | RUBBER MOUNTING | KOB |
| 57. | 24100J6470F1 | [1] | REMOTE-CONTROL ASSY, SEE FIGURE 03-002 | |
| 58. | 2416P8775D2 | [1] | BRACKET | BRACKET |
| 59. | 2416P8775D1 | [1] | BRACKET | BRACKET |
| 60. | 2416N3340 | [1] | SUPPORT | |
| 61. | 2416J823 | [1] | SUPPORT | SUPPORT |
| 62. | ZS18C12065 | [4] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
