| . . | 24100N4777F1 | [1] | CONTROL ASSY | |
| 1. | 2436R732F1 | [1] | SOLENOID VALVE | KOB |
| 2. | 2436R688F2 | [1] | SOLENOID VALVE | KOB |
| 3. | 2436R688F1 | [2] | SOLENOID VALVE | KOB |
| 4. | 2436R757F1 | [1] | VALVE, REDUCTION | VALVE, REDUCTION |
| 5. | 2479R1337F1 | [1] | PRESSURE SWITCH | KOB |
| 5-1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 5-2. | NSS | [1] | NOT SOLD SEPARAT | CONSCREW, ADJUSTING |
| 5-3. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 5-4. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 5-5. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER |
| 5-6. | NSS | [1] | NOT SOLD SEPARAT | CONPACKING |
| 5-7. | NSS | [1] | NOT SOLD SEPARAT | CONSHIM |
| 5-8. | NSS | [1] | NOT SOLD SEPARAT | CONSHIM |
| 5-9. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 5-12. | NSS | [1] | NOT SOLD SEPARAT | CONINDICATOR |
| 5-13. | NSS | [1] | NOT SOLD SEPARAT | CONWASHER |
| 5-14. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| 5-15. | NSS | [1] | NOT SOLD SEPARAT | CONSWITCH |
| 5-20. | NSS | [1] | NOT SOLD SEPARAT | CONCAP |
| 5-26. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON ASSY |
| 5-27. | 2479R1337S27 | [1] | O-RING | |
| 5-34. | 2479R1337S34 | [1] | O-RING | |
| 5-36. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 5-37. | NSS | [2] | NOT SOLD SEPARAT | CONSCREW |
| 5-40. | NSS | [2] | NOT SOLD SEPARAT | CONMACHINESCREW |
| 5-43. | NSS | [4] | NOT SOLD SEPARAT | CONMACHINESCREW |
| 5-44. | NSS | [1] | NOT SOLD SEPARAT | CONSETSCREW |
| 5-45. | NSS | [1] | NOT SOLD SEPARAT | CONSETSCREW |
| 5-49. | NSS | [1] | NOT SOLD SEPARAT | CONPACKING |
| 5-50. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, PROTECTIVE |
| 5-52. | NSS | [3] | NOT SOLD SEPARAT | CONSCREW, TAPPING |
| 5-53. | NSS | [1] | NOT SOLD SEPARAT | CONCONNECTOR |
| 6. | 2444T2596 | [1] | CONNECTOR | |
| 7. | ZX58N16080 | [1] | FLEXIBLE HOSE | KOB800mm Long (31-1/2 in) |
| 8. | ZF23H10004 | [2] | HYD CONNECTOR | KOB |
| 9. | ZX56N04270 | [1] | HOSE | |
| 10. | ZX56N04060 | [1] | HOSE | HOSE |
| 11. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 12. | 2416P11993 | [1] | BRACKET | BRACKET |
| 13. | 24100N4776F2 | [1] | WIRING, ELEC, SEE FIGURE 05-015 | |
| 14. | 2420R537D360 | [2] | HOSE,9.60mm ID x 3600mm L | KOB |
| 15. | 2420R537D120 | [2] | HOSE ASSY.,9.60mm ID x 1200mm L | KOB1200mm Long (47-1/4 in) Superseded by part number: HX21E06120DX |
| 16. | 2420R349D180 | [3] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 17. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 18. | 2420R349D320 | [1] | HOSE ASSY. | KOB3200mm Long (126 in) |
| 19. | 2420R349D070 | [2] | HOSE,700.00 mm | KOB700mm Long (27-9/16 in) |
| 20. | 2420R349D140 | [1] | HOSE,6.35mm ID x 1400mm L | KOB1/4" PF |
| 21. | 2420R349D050 | [1] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 22. | ZX15K08013 | [1] | TUBE, NYLON | TUBE, NYLON |
| 23. | ZX15K08005 | [3] | TUBE | KOB |
| 24. | ZX15K08011 | [1] | TUBE,N2 | TUBE,N2 |
| 25. | ZX15K08050 | [2] | PLASTIC-RUBBER TUBE | KOB |
| 26. | 2444Z2335 | [4] | CONNECTION | KOB |
| 27. | ZH52X04000 | [2] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 28. | ZS18C05050 | [8] | SCREW,Hex, M5 x 50mm | KOBM05x0.8x50mm |
| 29. | 2420N458D06020 | [4] | SCREW,Hex Socket Head, M6 x 20mm | KOB Superseded by part number: ZS28C06020 |
| 30. | ZN18C06005 | [4] | NUT | KOBM06x1.0mm |
| 31. | ZW26X06000 | [4] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 32. | ZW26X05000 | [8] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 33. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 34. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 35. | ZH32X04000 | [7] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 36. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 37. | ZH31M08004 | [4] | ELBOW | KOB |
| 38. | ZH51K08000 | [3] | TEE | KOB |
| 39. | 2444Z2734 | [1] | TEE | TEE |
| 40. | 2444P1098D2 | [1] | HYD CONNECTOR | KOB3/8" PF x 70mm Long (Incls. O-Ring ZD12P01400) |
| 41. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 42. | ZH42X06000 | [4] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006) |
| 43. | 2444P1171D3 | [3] | HYD CONNECTOR | KOB Superseded by part number: 72217408 |
| 44. | 2444T3324 | [1] | TEE | KOB |
| 45. | ZG22E04000 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 46. | ZG52U04000 | [1] | TEE | KOB |
| 47. | ZF23G10004 | [2] | HYD CONNECTOR | KOB |
| 48. | 2432Z290 | [15] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 49. | 2432N1136 | [1] | CHART LABEL | CHART LABEL |
