神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (04-003[01]) - HYDR LINES, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
631 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X2440F1 | [1] | HYDR LINES, UPP | |
| 1. | 2436U1927F2 | [1] | CONTROL VALVE | KOB |
| 2. | 2436U1928F2 | [1] | VALVE, CONTROL | VALVE, CONTROL |
| 3. | 2436R387F1 | [1] | VALVE, CHECK | VALVE, CHECK |
| 5. | 2416N4403 | [1] | BRACKET | |
| 6. | 2418P14561 | [1] | PIPE | KOB |
| 7. | 2418P14552 | [1] | SUCTION PIPE | KOB |
| 8. | 2418P15808 | [1] | PIPE, SUCTION | |
| 9. | 2418P17317 | [1] | TUBE | TUBE |
| 13. | 2418T9729 | [2] | TUBE | KOB |
| 14. | 2418N2904 | [1] | TUBE | KOBTUBE |
| 15. | 2418T15726 | [1] | TUBE | |
| 17. | 2418N2792 | [1] | MANIFOLD | MANIFOLD |
| 18. | 2418P14554 | [1] | TUBE | TUBE |
| 19. | 2418T7189D2 | [1] | TUBE | TUBE |
| 20. | 2418N4516 | [1] | TUBE | |
| 21. | 2418P14553 | [1] | TUBE | KOB |
| 22. | 2418T7002D3 | [1] | FLEXIBLE HOSE | KOB |
| 23. | 2418T7002D2 | [1] | FLEXIBLE HOSE | KOB |
| 24. | 2444Z1697D1 | [1] | HOSE | KOB |
| 25. | ZX21M12046 | [1] | FLEXIBLE HOSE | KOB460mm Long (18-7/64 in) Superseded by part number: ZX21M12050 |
| 26. | ZX68S16115 | [2] | FLEXIBLE HOSE | KOB |
| 27. | ZG15F03800 | [1] | COUPLING | KOB |
| 28. | ZG15F05100 | [3] | COUPLING | KOB |
| 29. | ZG15F04500 | [5] | COUPLING | KOB |
| 30. | ZF33F22012 | [1] | ELBOW | KOB |
| 31. | 2416T11552 | [1] | BRACKET | |
| 32. | 2416T4348 | [2] | CLAMP | CLAMP |
| 33. | 2432T1588 | [4] | CLAMP | KOB |
| 34. | 2420T2948D5 | [5] | U-BOLT | KOBM08x1.25x ID 45 x 80.5mm Long |
| 35. | 2420T2948D4 | [1] | BOLT | KOBU-Bolt -- M08x1.25x ID 51 x 83.5mm Long |
| 36. | R44T0187 | [2] | CONNECTOR | CONNECTOR |
| 37. | 2444R715D16 | [1] | CONNECTOR | CONNECTOR |
| 38. | ZF53B22000 | [1] | TEE | KOB |
| 39. | 2420Z804 | [2] | LOCK NUT | KOB |
| 40. | 2420T2948D6 | [1] | U-BOLT | KOBM08x1.25x ID 64 x 100mm Long |
| 41. | ZC15X08000 | [4] | CLIP | KOB |
| 42. | ZC15X10500 | [8] | CLIP | KOB |
| 43. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 44. | ZD12P03400 | [8] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 45. | ZD11G05000 | [4] | O-RING,3.1mm Thk x 49.4mm ID, 70 Duro | KOBO-Ring -- ID 49.40 ± 0.45 x OD 55mm |
| 46. | ZD12P04400 | [2] | O-RING | KOB |
| 47. | ZD12P04200 | [1] | O-RING | KOBID 41.70 ± 0.39 x OD 48.7mm |
| 48. | ZE13X16000 | [12] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 49. | ZE72X04000 | [3] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 50. | 2418T15473 | [1] | SHIM | |
| 51. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 52. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 53. | ZS18C10020 | [4] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 54. | ZS18C12045 | [24] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| 55. | ZS18C12060 | [3] | SCREW,Hex, M12 x 60mm | KOBM12x1.75x60mm |
| 56. | ZS18C12070 | [4] | SCREW,Hex, M12 x 70mm | KOBM12x1.75x70mm |
| 57. | ZS18C12110 | [3] | SCREW,Hex, M12 x 110mm | KOBM12x1.75x110mm |
| 58. | ZS18C16040 | [8] | SCREW,Hex, M16 x 40mm | KOBM16x2.0x40mm |
| 59. | 2420N458D12035 | [20] | SCREW,Hex Socket Head, M12 x 35mm | KOB Superseded by part number: ZS28C12035 |
| 60. | 2420N458D12070 | [8] | SCREW | KOB |
| 61. | ZN18C08007 | [28] | NUT | KOBM08x1.25mm |
| 62. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 63. | ZN18C12010 | [10] | NUT | KOBM12x1.75mm |
| 64. | ZW16X08000 | [14] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 65. | 2418T5373C2 | [18] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 66. | ZW16H12000 | [10] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 67. | ZW16H16000 | [8] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 68. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 69. | ZW26X12000 | [34] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 70. | ZW26X16000 | [8] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 71. | ZW26K12000 | [28] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 72. | 2444R973D1 | [2] | HOSE | KOB |
| 73. | 2418P19315 | [1] | TUBE | |
| 74. | 2416J830 | [1] | STAND, VALVE | |
| 75. | 2418N4558 | [1] | TUBE | TUBE |
