神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (05-005) - PUMP ASSY, CONNECT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
785 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J3962F11 | [1] | PUMP ASSY, CONNECT | |
| 2. | 2441U366F1 | [1] | PUMP | KOB |
| 3. | 2418U153F1 | [1] | COUPLING | KOB |
| 3-1. | 2453U147S40 | [4] | ELEMENT | KOB Superseded by part number: 2453U147S40M |
| 3-2. | 2453U147S41 | [4] | INSERT | KOB |
| 3-3. | 2453U147S42 | [4] | BUSHING | KOB |
| 3-4. | 2418U153S4 | [4] | SCREW | KOB |
| 3-5. | 2418U153S5 | [4] | SCREW | KOB |
| 3-6. | ZP26D08016 | [8] | ROLL PIN | KOB |
| 3-7. | ZS73C20025 | [2] | SET OF SCREWS | KOB |
| 3-8. | 2418P7532 | [1] | COUPLING | KOBHUB |
| 4. | 2418P7485 | [1] | FLANGE | KOB |
| 5. | ZS23C10030 | [12] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 8. | ZD12G05500 | [1] | O-RING,3.1mm Thk x 54.4mm ID, 90 Duro | KOBO -- ID 54.40 ± 0.49 x OD 60mm |
| 12. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 13. | ZW16K10000 | [2] | WASHER | KOBID 10.5 x OD 18 x Th 2.0mm |
| 20. | 2441U681F2 | [1] | PUMP, SEE FIGURE 05-006 | |
