凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.120.01.AC) - FOAM MARKER PUMP AND BOOM SUPPLY LINES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
767 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87727677
|
[1] |
PUMP,12V
|
BN
Diaphragm, 1 GPM, 12V, Foam Transfer
|
| 2. |
BN310265
|
[4] |
WASHER
|
BN
10, Stainless Steel
|
| 3. |
BN303136
|
[4] |
NUT
|
BN
10-32, NLN, G5
|
| 4. |
BN310446
|
[2] |
HOSE CLAMP
|
BN
#12, Stainless Steel
|
| 5. |
BN310450
|
[3] |
HOSE CLAMP
|
BN
#3, Stainless Steel
|
| 6. |
87266748
|
[1] |
HOSE
|
BN
3/8" x 10.5" Clear
|
| 7. |
343436A1
|
[1] |
FITTING
|
BN
3/4" MPT X 3/8" Hose Barb, Poly
|
| 8. |
BN324892
|
[1] |
FILTER STRAINER
|
BN
3/4", "Y" Style, 40 Mesh, Poly
|
| 9. |
87266749
|
[1] |
HOSE
|
BN
3/4" X 18" Clear
|
| 10. |
BN67050
|
[2] |
BOLT,1/4"-20 X 3.00", Stainless Steel
|
BN
|
| 11. |
BN73562
|
[2] |
ELBOW,90 Degree Elbow, 3/4" Male NPT x 3/4" Hose Barb, Poly
|
BN
3/4" NPT x 3/4" Hose Barb, Poly Superseded by part number: 34306061
|
| 12. |
BN73564
|
[1] |
VALVE
|
BN
3/4" Ball Poly 2 Way, Full, Poly Superseded by part number: 413088A1
|
| 13. |
BN73565
|
[1] |
NIPPLE,3/4" Male NPT x 3/4" Male NPT, Poly
|
BN
3/4" Short Pipe, Poly Superseded by part number: 405788A1
|
