凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.120.01.AD) - FOAM MARKER AIR SUPPLY SYSTEM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
527 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86986598
|
[1] |
MOUNTING PLATE
|
BN
Air Regulator
|
| 2. |
87388151
|
[1] |
REGULATOR
|
BN
Air Pressure
|
| 3. |
86986803
|
[1] |
GAUGE
|
CUR
0-30 PSI, 1/8" NPT
|
| 4. |
87265091
|
[2] |
FITTING
|
BN
1/4" NPT x 1/2" Hose Barb, 90º, Poly
|
| 5. |
BN324022
|
[2] |
HOSE CLAMP
|
BN
#8, Stainless Steel
|
| 6. |
BN54239
|
[1] |
HOSE,12.7mm ID x 3048mm L
|
BN
Black-1/2 EPDM, Discharge, Bulk, Cut to Length of 120"
|
| 7. |
87388327
|
[1] |
NUT
|
BN
Panel Mount, Plastic
|
| 8. |
BN2407985
|
[2] |
SCREW,Hex, #10 - 24 x 3/4"
|
BN
10-24 x 3/4", HH, SST
|
| 9. |
BN310266
|
[2] |
BHD LOCK NUT,#10-24, Nylon, Stainless Steel
|
BN
|
| 10. |
BN73511
|
[1] |
FITTING
|
BN
90° 1/2" Female NPT x 1/2" Male NPT Superseded by part number: 87414643
|
| 11. |
217-1143
|
[1] |
TEE,1/2"-14 Female x 1/2"-14 Male Br
|
CAS
Not Shown
|
| 12. |
218-456
|
[1] |
HYD CONNECTOR,3/4" - 16 Male JIC x 1/2" - 14 Male NPTF
|
CAS
Not Shown Superseded by part number: 132341
|
