凯斯零件查询(810) - FLEX-AIR APPLICATOR - 2012 (2/12-) (78.120.02.AE) - FOAM MARKER MIXING CHAMBER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
543 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN307636
|
[1] |
CHAMBER
|
BN
Foam Mixing, Assembly
|
| 2. |
21965
|
[1] |
SCREEN
|
SAS
Foam Head, 3/8" Screen Strainer
|
| 3. |
BN313211
|
[1] |
NIPPLE
|
BN
Hex, 1-1/4"
|
| 4. |
21964
|
[1] |
HOUSING
|
SAS
Base, Foam Mixing Chamber
|
| 5. |
21966
|
[1] |
GASKET
|
SAS
Foam Mixing Chamber
|
| 6. |
21967
|
[1] |
HOUSING
|
SAS
Top, Foam Mixing Chamber
|
| 7. |
NSS
|
[6] |
NOT SOLD SEPARAT
|
CON
10-24 x 7/8", Stainless Steel Screw
|
