| . . | 24100X2085F3 | [1] | BOOM ASSY | |
| 1. | 2411X927F1 | [1] | BOOM | BOOM |
| 1-1. | 2411X927 | [1] | BOOM | BOOM |
| 1-31. | 2405T1108 | [2] | BUSHING | KOB |
| 1-32. | 2418T9816 | [1] | SPACER | KOB |
| 2. | 2438U776F1 | [2] | BUCKET CYLINDER | KOB Superseded by part number: 2438U776F2 |
| 3. | 2438U1323F1 | [1] | CYLINDER | KOB Superseded by part number: 2438U1323F2 |
| 4. | 2418P11325D2 | [1] | TUBE | KOB |
| 5. | 2418P11325D1 | [1] | TUBE | KOB |
| 6. | 2418P10049D2 | [1] | TUBE | TUBE |
| 7. | 2418P10049D1 | [1] | TUBE | TUBE |
| 8. | 2418T14266 | [1] | TUBE | KOB |
| 9. | 2418P10050 | [1] | TUBE | KOB |
| 10. | 2418N2784 | [2] | TUBE | KOB |
| 11. | 2418P15561 | [2] | TUBE | KOB |
| 12. | 2418P10051D1 | [1] | TUBE | KOB |
| 13. | 2418P10051D2 | [1] | TUBE | KOB |
| 14. | ZX28N16120 | [2] | HOSE | KOB Superseded by part number: ZX58N16120 |
| 15. | 2420R349D170 | [2] | FLEXIBLE HOSE | KOB1700mm Long (66-59/64 in) Superseded by part number: HX21E04170DX |
| 16. | 2420R349D320 | [2] | HOSE ASSY. | KOB3200mm Long (126 in) |
| 17. | 2420R349D370 | [1] | HOSE,3700.00 mm | KOB Superseded by part number: HX21E04370DX |
| 18. | ZF23B35000 | [2] | HYD CONNECTOR | KOB |
| 19. | ZH22Z04000 | [7] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 20. | ZH32Z04000 | [3] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 21. | 2432T1264 | [4] | CLAMP | KOB |
| 22. | 2432T1213D2 | [6] | CLAMP | KOB |
| 23. | 2432T1476 | [1] | CLAMP | KOB |
| 24. | 2416T3655 | [3] | CLAMP | KOB |
| 25. | 2416T17769 | [2] | BRACKET | KOB |
| 26. | ZN18C06005 | [2] | NUT | KOBM06x1.0mm |
| 27. | 2419P1852 | [1] | PIN | KOB |
| 28. | 2419P1853 | [1] | PIN | KOB |
| 29. | 2419P2106 | [1] | PIN | KOB |
| 30. | 2416T9975 | [2] | COLLAR | KOB |
| 31. | ZS18C20160 | [5] | SCREW,Hex, M20 x 160mm | KOBM20x2.50x160mm |
| 33. | ZS18C12045 | [4] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| 34. | ZS18C12050 | [2] | SCREW,Hex, M12 x 50mm | KOBM12x1.75x50mm |
| 35. | ZS18C12065 | [6] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 36. | ZS18C08012 | [6] | SCREW,Hex, M8 x 12mm | KOBM08x1.25x12mm |
| 37. | 2420T2747D5 | [2] | SHIM,102mm ID x 170mm OD x 3.2mm Thk | KOBID 102 x OD 170 x Th 3.2mm |
| 38. | ZS18C12075 | [24] | SCREW,Hex, M12 x 75mm | KOBM12x1.75x75mm |
| 39. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm |
| 40. | ZN18C20016 | [10] | NUT | KOBM20x2.5mm |
| 41. | ZW16H12000 | [40] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 42. | ZW16H08000 | [6] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 43. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 44. | 2420T2747D2 | [4] | SHIM,102mm ID x 170mm OD x 1.2mm Thk | KOBID 102 x OD 170 x Th 1.2mm |
| 45. | 2432T2958 | [2] | CLAMP | KOB |
| 46. | ZD12P03400 | [6] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 47. | 2445R138D9 | [2] | SEAL,100mm ID x 120mm OD x 4mm Thk | KOBDust -- ID 100 x OD 120 x Th 4mm |
| 48. | ZG91S02000 | [8] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 49. | R20T0020 | [1] | NUT | KOB |
| 50. | ZP15D10100 | [1] | COTTER PIN | KOBOD 10 x 100mm Long |
| 51. | R16T0152D14 | [1] | WASHER | KOBFlat -- ID 65 x OD 160 x Th 12.0mm |
| 53. | 2419T4391 | [1] | PIN | KOB |
| 54. | 2419T3509 | [2] | PIN | KOB |
| 55. | ZX28N16160 | [4] | HOSE | KOB |
| 56. | 2418T13646 | [1] | PLATE | KOB |
| 57. | ZS18C20060 | [2] | SCREW,Hex, M20 x 60mm | KOBM20x2.50x60mm |
| 58. | ZW16H20000 | [2] | WASHER | KOBID 21 x OD 40 x Th 4.5mm |
| 59. | B16T0442D13 | [8] | SHIM,160mm OD x 92mm ID x 1.2mm Thk | KOBID 92 x OD 160 x Th 1.2mm |
| 60. | ZS23C12035 | [2] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 61. | 2416T5904 | [1] | CLAMP | KOB |
| 62. | 2432Z290 | [7] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 63. | ZS18C12090 | [2] | SCREW,Hex, M12 x 90mm | KOBM12x1.75x90mm |
| 69. | ZX58N16083 | [4] | HOSE | KOB830mm Long (32-43/64 in) |
