神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (06-009) - INSTAL, CRAWLER TRACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
428 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1980F5 | [1] | INSTAL, CRAWLER TRACK | |
| 2. | 2420T5546 | [408] | BOLT | KOB |
| 3. | 2420T2751 | [408] | NUT | KOB |
| 4. | 2424N141 | [102] | SHOE | KOB Superseded by part number: 2415N371 |
| 9. | 24100N4548F2 | [2] | TRACK ASSY | KOB Superseded by part number: 24100J10382F3 |
| 9-1. | 2424P104D3 | [49] | CHAIN | KOB |
| 9-2. | 2424P104D4 | [49] | CHAIN | KOB |
| 9-3. | 2405T1206 | [49] | BUSHING | KOBTRACK |
| 9-4. | 2419T4517 | [49] | PIN | KOB |
| 9-5. | 2405T1207 | [2] | BUSHING | KOBMASTER |
| 9-6. | 2419T4518 | [2] | PIN | KOB Superseded by part number: 2419T7212 |
| 9-8. | 2418T8622 | [4] | COLLAR CLAMP | KOB |
| 9-9. | 2424P105D3 | [2] | CONNECTING LINK | KOB |
| 9-10. | 2424P105D4 | [2] | CONNECTING LINK | KOB |
| 9-11. | 2419T3151 | [2] | PIN | KOB |
| . . | 24100P1980F6 | [1] | INSTAL, CRAWLER TRACK | |
| 5. | 2424N142 | [102] | SHOE, 800 | SHOE, 800 |
| . . | 24100P1980F8 | [1] | INSTAL, CRAWLER TRACK | |
| 8. | 2424N178 | [102] | SHOE | |
