神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-009) - VALVE ASSY, BY-PASS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
818 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1275F1 | [1] | VALVE ASSY VALVE ASSY, BY-PASS, CONSISTS OF THE FOLLOWING PARTS | VALVE ASSY VALVE ASSY, BY-PASS, CONSISTS OF THE FOLLOWING PARTS |
| 311. | 2436U1275S311 | [1] | SPOOL | |
| 321. | 2436U1275S321 | [1] | SPRING | |
| 322. | 2436U1275S322 | [1] | SPRING | |
| 331. | 2436U1275S331 | [1] | SEAT, SPRING | |
| 351. | 2436U1275S351 | [1] | PLUG | |
| 361. | ZD12G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 371. | 2436U1208S352 | [1] | SETSCREW | |
