神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-017[02]) - VALVE ASSY, CONTROL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
872 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1928F1 | [1] | VALVE ASSY, CONTROL CONSISTS OF THE FOLLOWING PARTS | |
| . . | 2436U1928F2 | [1] | VALVE, CONTROL ASSY, CONSISTS OF THE FOLLOWING PARTS | VALVE, CONTROL ASSY, CONSISTS OF THE FOLLOWING PARTS |
| 001. | 24036R77F5 | [1] | VALVE PRESSURE RELIE | KOB |
| 106. | NSS | [2] | NOT SOLD SEPARAT | CONCASING |
| 110. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 151. | 2436U741S462 | [4] | PLUG | KOB |
| 161. | ZD12G11000 | [2] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOBID 109.4 ± 0.91 x OD 115mm |
| 162. | 2436U665S162 | [4] | O-RING | KOB Superseded by part number: 2436U1345S162 |
| 202. | 2436U1928S202 | [2] | COVER, SPRING | |
| 204. | 2436U1928S204 | [3] | COVER, SPOOL | |
| 262. | 2436U665S262 | [5] | O-RING | KOB Superseded by part number: 2436U1457S162 |
| 263. | ZD12P01100 | [10] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 271. | ZS23C06025 | [20] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 315. | NSS | [2] | NOT SOLD SEPARAT | CONSPOOL |
| 318. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 319. | 2436U1928S319 | [1] | ORIFICE | |
| 323. | 2436U1744S323 | [2] | SPRING | |
| 325. | 2436U1744S325 | [2] | SPRING | |
| 328. | 2436U1928S328 | [2] | SPRING | |
| 334. | 2436U665S334 | [2] | SCREW | KOBSPACER Superseded by part number: 2436U1431S332 |
| 337. | 2436U665S337 | [4] | GUIDE, SPRING SEAT | GUIDE, SPRING SEAT |
| 338. | 2436U1928S338 | [2] | SEAT, SPRING | |
| 339. | 2436U1928S339 | [1] | SEAT, SPRING | |
| 351. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 514. | 2436U1928S514 | [3] | PLUNGER | |
| 515. | 2436U1928S515 | [2] | BALL | |
| 516. | 2436U1928S516 | [1] | PLUNGER | |
| 524. | 2436U1928S524 | [4] | SPRING | |
| 534. | 2436U1928S534 | [2] | SEAT | |
| 540. | 2436U1928S540 | [4] | ORIFICE | ORIFICE |
| 552. | 2436U1219S153 | [2] | PLUG | KOB |
| 554. | 2436U1928S554 | [4] | PLUG | KOBPLUG Superseded by part number: YN30V00001S551 |
| 555. | 2436U1807S251 | [2] | PLUG | PLUG |
| 562. | ZD12G02500 | [2] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 564. | 2483U180S166564 | [4] | O-RING | |
| 565. | ZP12P01000 | [2] | O-RING | |
| 602. | 24036R77F4 | [2] | VALVE PRESSURE RELIE | KOBF1 ONLY |
| 604. | 2436U1281F1 | [2] | VALVE PRESSURE RELIE | KOBF2 ONLY |
| 820. | 2436U1272F1 | [1] | VALVE ASSY | |
| 951. | 2436U1795S251 | [4] | PLUG | |
| 961. | ZD12P01100 | [4] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 975. | 2436U1928S975 | [2] | CAPSCREW | |
| 976. | ZS23C18090 | [2] | SET SCREW,Hex Socket Head, M18 x 90mm | KOBM18x2.50x90mm |
| 977. | ZS23C18075 | [2] | SCREW,Hex Socket Head, M18 x 75mm | KOBM18x2.50x75mm |
| 991. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| . . | 2436U1928R100 | [1] | REPAIR KIT CONSISTS OF REF 106, 315, 351 | REPAIR KIT CONSISTS OF REF 106, 315, 351 |
| . . | 2436U1928R110 | [1] | REPAIR KIT | KOBCONSISTS OF REF 110, 318, 319 |
