神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-018) - CYLINDER ASSY, BOOM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
953 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U776F1 | [1] | BUCKET CYLINDER | KOBASSY, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U776F2 |
| 1. | 2438U776S1 | [1] | LINER, ENGINE CYLIND | KOBASSY |
| 2. | 2438U776S2 | [1] | PISTON ROD | KOBASSY |
| 3. | 2438U776S3 | [1] | CYLINDER | KOBHEAD, CYLINDER |
| 4. | 2438U776S4 | [1] | BUSHING | KOB |
| 5. | 2438U776S5 | [1] | SNAP RING | KOB |
| 6. | 2438U776S6 | [1] | RING, BUFFER | RING, BUFFER |
| 7. | 2438U776S7 | [1] | RING | |
| 8. | 2438U776S8 | [1] | BACK-UP RING | KOB |
| 9. | 2438U776S9 | [1] | RING | KOB |
| 10. | 2438U776S10 | [1] | O-RING | |
| 11. | 2438U776S11 | [1] | RING, BACK-UP | |
| 12. | 2438U776S12 | [8] | BOLT, SOCKET | |
| 13. | 2438U776S13 | [1] | BUSHING, SPHERICAL BEARING, CUSHION | BUSHING, SPHERICAL BEARING, CUSHION |
| 14. | 2438U776S14 | [1] | PISTON | KOB |
| 15. | 2438U776S15 | [1] | RING | KOBRING ASSY, SEAL Superseded by part number: 2438U1324S15 |
| 16. | 2438U776S16 | [2] | RING | |
| 17. | 2438U776S17 | [2] | RING | |
| 18. | 2438U776S18 | [1] | NUT | KOB |
| 19. | 2438U776S19 | [1] | SHIM | KOB |
| 20. | 2438U776S20 | [1] | PIN | PIN |
| 21. | 2438U776S21 | [1] | RING, SNAP | RING, SNAP |
| 22. | 2438U776S22 | [1] | BUSHING | KOB |
| 23. | 2438U776S23 | [2] | RING, WIPER | RING, WIPER |
| 24. | 2438U776S24 | [1] | BUSHING | KOB |
| 25. | 2438U776S25 | [2] | SEAL,100mm ID x 120mm OD x 4mm Thk | KOB Superseded by part number: 2445R138D9 |
| 26. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| . . | 2438U776R100 | [1] | REPAIR KIT | KOBREPAIR, CONSISTS OF REF 6 - 11 |
| . . | 2438U776R110 | [1] | REPAIR KIT CONSISTS OF REF 15 - 17 | REPAIR KIT CONSISTS OF REF 15 - 17 |
