神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-021) - PUMP, GEAR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
632 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U366F1 | [1] | PUMP | KOBCONSISTS OF THE FOLLOWING PARTS |
| 1. | 2441U366S1 | [1] | GEAR ASSY | |
| 6. | 2437U157S6 | [1] | LARGE PLATE | KOBPLATE, LARGE Superseded by part number: 2441U291S6 |
| 7. | 2437U157S7 | [1] | SIDE PLATE | KOB Superseded by part number: 2441U291S7 |
| 8. | 2437U157S8 | [1] | SEAL | KOB |
| 9. | 2437U157S9 | [1] | GASKET | KOB |
| 10. | 2437U157S10 | [1] | GASKET | KOB |
| 11. | 2437U157S11 | [1] | O-RING | KOB |
| 12. | 2437U157S12 | [2] | DOWEL | KOB |
| 13. | 2437U157S13 | [1] | OIL SEAL | KOB |
| 14. | 2437U157S14 | [4] | SCREW | KOB |
| 15. | 2441R6S15 | [1] | LOCKING RING | KOB Superseded by part number: ZR26X03200 |
| . . | 2441U366S100 | [1] | SEAL KIT | KOBCONSISTS OF REF 8 - 11, 13, 15 |
