神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-020) - CYLINDER ASSY, BUCKET Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
118 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1324F1 | [1] | CYLINDER | KOBASSY, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U1324F2 |
| 1. | 2438U1324S1 | [1] | TUBE | KOBASSY |
| 2. | 2438U1324S2 | [1] | PISTON ROD | KOBASSY |
| 3. | 2438U1324S3 | [1] | HEAD, CYLINDER | HEAD, CYLINDER |
| 4. | 2438U1324S4 | [1] | BUSHING | KOB |
| 5. | 2438U1324S5 | [1] | SNAP RING | KOB |
| 6. | 2438U1324S6 | [1] | RING | KOB |
| 7. | 2438U1324S7 | [1] | O-RING | KOB |
| 8. | 2438U1324S8 | [1] | RING | KOB |
| 9. | 2438U1324S9 | [1] | WIPER ARM | KOB Superseded by part number: 2438U1170S32 |
| 10. | 2438U1324S10 | [1] | O-RING | O-RING |
| 11. | 2438U1324S11 | [1] | BACK-UP RING | KOB |
| 12. | 2438U1323S12 | [8] | SCREW | KOBSOCKET |
| 13. | 2438U1324S13 | [1] | SPACER | KOBBEARING, CUSHION |
| 14. | 2438U1324S14 | [1] | PISTON | KOB |
| 15. | 2438U1324S15 | [1] | SEALING RING | KOBASSY |
| 16. | 2438U1324S16 | [2] | RING | KOB |
| 17. | 2438U1324S17 | [2] | RING | KOB |
| 18. | 2438U1324S18 | [1] | NUT | KOB |
| 19. | 2438U1324S19 | [1] | SHIM | KOB |
| 20. | 2438U1324S20 | [1] | PIN | KOB |
| 21. | 2438U1324S21 | [1] | SNAP RING | KOB |
| 22. | 2438U1324S22 | [2] | BUSHING | KOB |
| 23. | 2438U1323S23 | [4] | WIPER BLADE | KOB Superseded by part number: 2445R138D8 |
| 24. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| . . | 2438U1324R100 | [1] | SEAL KIT | KOBREPAIR, CONSISTS OF REF 6 - 11 |
| . . | 2438U1324R110 | [1] | REPAIR KIT | KOBREPAIR, CONSISTS OF REF 15 - 17 |
