神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-023) - MOTOR ASSY, HYDR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
524 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U682F1 | [1] | MOTOR, HYDR ASSY, CONSISTS OF THE FOLLOWING PARTS | MOTOR, HYDR ASSY, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2441U354S1 | [7] | PISTON | |
| 101. | 2441U354S101 | [1] | SHAFT, DRIVE | |
| 103. | 2441U354S103 | [1] | OIL SEAL | KOB |
| 104. | 2441U354S104 | [1] | BALL BEARING | KOB Superseded by part number: 25T819D10 |
| 105. | 2441U631S432 | [1] | SNAP RING STOP | SNAP RING STOP |
| 106. | 2441U354S106 | [1] | SHIM | KOB |
| 109. | 2441U354S109 | [1] | SPACER | SPACER |
| 111. | 2441U354S111 | [1] | ROLLER CAGE BEARING | KOBSPHERICAL |
| 122. | 2441U354S122 | [1] | RING, SET | RING, SET |
| 126. | 2441U354S126 | [1] | PLATE | |
| 127. | 2441U354S127 | [14] | SCREW | |
| 142. | 2441U354S142 | [1] | PIN | PIN |
| 143. | 2441U354S143 | [1] | PIN | KOB |
| 151. | 2441U354S151 | [1] | CYLINDER | |
| 161. | 2441U354S161 | [1] | ROD | |
| 165. | 2441U354S165 | [1] | SPRING | KOB |
| 171. | 2441U682S171 | [1] | PLATE, VALVE | |
| 251. | 2441U476S249 | [1] | COVER, FRONT | COVER, FRONT |
| 253. | 2441U682S253 | [1] | COVER, VALVE | COVER, VALVE |
| 286. | 2441U682S286 | [1] | O-RING | O-RING |
| 288. | 2441U682S288 | [7] | SCREW,Hex Socket Head, M14 x 45mm | KOB Superseded by part number: ZS28C14045 |
| 301. | 2441U682S301 | [1] | CASING | |
| 317. | ZD12G12500 | [1] | O-RING,124.40mm ID x 130.60mm OD x 3.10mm | KOBID 124.40 ± 1.01 x OD 130mm |
| 320. | ZR26X12500 | [1] | RING | KOBLOCK |
| . . | 2441U682R10 | [1] | SHAFT ASSY, DRIVE REPAIR KIT, CONSISTS OF REF 1, 101, 111, 122, 126, 127, 161 | SHAFT ASSY, DRIVE REPAIR KIT, CONSISTS OF REF 1, 101, 111, 122, 126, 127, 161 |
| . . | 2441U682R20 | [1] | CYLINDER ASSY REPAIR KIT, CONSISTS OF REF 151, 171 | CYLINDER ASSY REPAIR KIT, CONSISTS OF REF 151, 171 |
| . . | 2441U682R30 | [1] | COVER ASSY | KOBREPAIR KIT, CONSISTS OF REF 142, 143, 253 |
