| . . | 2441U716F1 | [1] | PUMP | KOBNO.1, CONSISTS OF THE FOLLOWING PARTS |
| . . | 2441U716F2 | [1] | PUMP | KOBASSY, NO.2, CONSISTS OF THE FOLLOWING PARTS |
| . . | 2441U716F3 | [1] | PUMP ASSY, NO.1, CONSISTS OF THE FOLLOWING PARTS | PUMP ASSY, NO.1, CONSISTS OF THE FOLLOWING PARTS |
| . . | 2441U716F4 | [1] | PUMP ASSY, NO.2, CONSISTS OF THE FOLLOWING PARTS | PUMP ASSY, NO.2, CONSISTS OF THE FOLLOWING PARTS |
| 40. | 2441U716S40 | [1] | HYDRAULIC VALVE | KOBBLOCK, F1 ONLY |
| 41. | 2441U716S41 | [1] | BLOCK | KOBF3 ONLY |
| 57. | 2441U716S57 | [1] | HYDRAULIC VALVE | KOBBLOCK, F2 ONLY |
| 58. | 2441U716S58 | [1] | BLOCK | KOBF4 ONLY |
| 111. | 2441U474S111 | [1] | SHAFT | KOB |
| 123. | 2441U474S123 | [1] | BEARING | KOB |
| 124. | 2441U474S124 | [1] | NEEDLE BEARING | KOB Superseded by part number: 2441U722S124 |
| 126. | 2441U474S126 | [1] | SHIM | KOB |
| 127. | 2441U474S127 | [1] | SPACER | KOB |
| 141. | NSS | [1] | NOT SOLD SEPARAT | CONCYLINDER |
| 142. | NSS | [9] | NOT SOLD SEPARAT | CONBUSHING |
| 151. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 152. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 153. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 156. | NSS | [1] | NOT SOLD SEPARAT | CONBEARING, SPHERICAL |
| 157. | 2441U474S157 | [4] | SPRING | KOB |
| 158. | 2441U474S158 | [1] | SHIM | KOB |
| 212. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 251. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET |
| 253. | NSS | [2] | NOT SOLD SEPARAT | CONMETAL |
| 254. | NSS | [2] | NOT SOLD SEPARAT | CONCLAMP |
| 255. | NSS | [2] | NOT SOLD SEPARAT | CONCLAMP |
| 261. | 2441U716S261 | [1] | COVER | COVER |
| 271. | 2441U474S271 | [1] | BELT | BELT |
| 273. | 2441U474S273 | [1] | RETAINER | RETAINER |
| 274. | 2441U474S274 | [1] | RIGID TUBE | KOB |
| 276. | 2441U474S276 | [1] | STOP | KOB |
| 280. | 2441U474S280 | [1] | SCREW | KOB |
| 312. | 2441U716S312 | [1] | COVER | |
| 314. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 315. | 2441U474S315 | [1] | RING, GUIDE | RING, GUIDE |
| 402. | ZS23C06040 | [4] | SCREW,Hex Socket Head, M6 x 40mm | KOBM06x1.0x40mm |
| 406. | ZS23C06016 | [4] | SCREW,Hex Socket Head, M6 x 16mm | KOBM06x1.0x16mm Superseded by part number: ZS28C06016 |
| 410. | ZS23C10025 | [4] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm Superseded by part number: ZS28C10025 |
| 423. | ZS23C20050 | [4] | SCREW,Hex Socket Head, M20 x 50mm | KOBM20x2.5x50mm |
| 444. | ZS23C12035 | [10] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 456. | NSS | [4] | NOT SOLD SEPARAT | CONCAPSCREW |
| 466. | 2441U667S466 | [2] | PLUG | KOB1/4" PF |
| 469. | 2441U436S469 | [1] | PLUG | KOB |
| 473. | 2441U436S473 | [1] | PLUG | PLUG |
| 474. | 2441U436S474 | [1] | PLUG | PLUG |
| 490. | 2438U1538S490 | [14] | PLUG | PLUG |
| 494. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 531. | 2441U716S531 | [1] | LEVER | LEVER |
| 532. | 2441U474S532 | [1] | PISTON | KOB |
| 534. | 2441U474S534 | [1] | STOPPER | STOPPER |
| 535. | 2441U716S535 | [1] | STOPPER | |
| 543. | 2441U474S543 | [1] | RING | KOB |
| 544. | 2441U436S544 | [1] | SCREW | KOB |
| 545. | 2441U436S545 | [1] | PIN | KOB |
| 551. | 2441U716S551 | [1] | COVER | |
| 572. | 2441U474S572 | [1] | COVER | |
| 615. | 2441U474S615 | [1] | LEVER | KOBLEVER |
| 617. | 2441U436S617 | [1] | PIN | KOB |
| 620. | 2441U436S620 | [1] | PIN | KOB |
| 651. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 653. | NSS | [1] | NOT SOLD SEPARAT | CONSLEEVE |
| 663. | 2441U716S663 | [1] | SEAT, SPRING | |
| 671. | 2441U716S671 | [1] | CASE, PISTON | |
| 675. | 2441U716S675 | [1] | PISTON | KOB |
| 676. | 2441U716S676 | [1] | SPRING | |
| 677. | 2441U716S677 | [1] | RING | |
| 691. | 2441U722S691 | [1] | COVER | |
| 702. | ZD12G03000 | [4] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 715. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 722. | ZD12P00600 | [1] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm |
| 724. | ZD12P00800 | [2] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 725. | ZD12P01000 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 727. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 732. | ZD12P01600 | [1] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 733. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 734. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 735. | ZD12P01200 | [2] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 743. | 2441U716S743 | [1] | O-RING | KOB Superseded by part number: 2441U474S743 |
| 745. | 2441U716S745 | [1] | O-RING | KOB |
| 750. | 2401U14S40 | [1] | O-RING | KOB Superseded by part number: 2441U716S750 |
| 754. | ZD12P00300 | [1] | O-RING | KOB |
| 755. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 774. | 2441U474S774 | [1] | OIL SEAL | KOB |
| 793. | 2441U474S793 | [4] | WASHER, SEALING | KOBSEAL WASHER Superseded by part number: 2441U722S793 |
| 801. | ZN11C08007 | [1] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 805. | ZN12C20016 | [2] | NUT | KOBM20x2.50mm |
| 822. | ZR16X04500 | [1] | RING | KOBRetaining -- ID 45 x OD 58 x Th 1.8mm |
| 868. | ZP26D05022 | [1] | ROLL PIN | KOB |
| 888. | 2441U474S888 | [1] | PIN | KOB |
| 924. | 2441U436S924 | [1] | SCREW | KOB Superseded by part number: 2441U722S924 |
| 926. | 2441U722S926 | [1] | SCREW | |
| 930. | 2441U716S930 | [2] | SCREW | |
| 938. | 2441U436S938 | [1] | PLUG | |
| 964. | 2436U969S964 | [1] | BALL | KOB |
| . . | 2441U716R10 | [1] | REPAIR KIT | KOBCONSISTS OF REF 151 - 152 |
| . . | 2441U716R20 | [1] | REPAIR KIT CONSISTS OF REF 141, 142, 314 | REPAIR KIT CONSISTS OF REF 141, 142, 314 |
| . . | 2441U716R30 | [1] | REPAIR KIT CONSISTS OF REF 153, 156 | REPAIR KIT CONSISTS OF REF 153, 156 |
| . . | 2441U716R40 | [1] | REPAIR KIT CONSISTS OF REF 212, 251, 253 - 255, 456, 938 | REPAIR KIT CONSISTS OF REF 212, 251, 253 - 255, 456, 938 |
| . . | 2441U716R50 | [1] | REPAIR KIT CONSISTS OF REF 651, 653 | REPAIR KIT CONSISTS OF REF 651, 653 |
