神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-028) - RELIEF VALVE, PORT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
552 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24036R76F1 | [1] | VALVE PRESSURE RELIE | KOBPORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 24036R76F2 | [1] | VALVE PRESSURE RELIE | KOBPORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 24036R76F3 | [1] | VALVE PRESSURE RELIE | KOBPORT CONSISTS OF THE FOLLOWING PARTS |
| . . | 24036R76F4 | [1] | RELIEF VALVE, PORT, CONSISTS OF THE FOLLOWING PARTS | |
| . . | 24036R76F5 | [1] | VALVE, RELIEF PORT, CONSISTS OF THE FOLLOWING PARTS | VALVE, RELIEF PORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 24036R76F6 | [1] | VALVE PRESSURE RELIE | KOBPORT, CONSISTS OF THE FOLLOWING PARTS |
| 01. | 24036R76S01 | [1] | BODY, F1 ONLY | |
| 02. | 24036R76S02 | [1] | BODY ASSY, F2 - F6 ONLY | |
| 102. | 24036R76S102 | [1] | PLUG | |
| 141. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 142. | ZD12P01500 | [1] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 151. | ZD12P01600 | [1] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 211. | 24036R76S211 | [1] | SPRING | |
| 301. | 24036R76S301 | [1] | SEAT | |
| 311. | 24036R75S311 | [1] | GUIDE, SPRING | |
| 312. | 24036R75S312 | [1] | FILTER | |
| 401. | 24036R75S401 | [1] | POPPET | KOB |
| 511. | 24036R75S511 | [1] | SPRING | KOB |
| 521. | 24036R75S521 | [1] | GUIDE, SPRING | |
| 531. | ZD12P00700 | [1] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 601. | 24036R75S601 | [1] | SPECIAL BOLT | KOB Superseded by part number: 2441U722S924 |
| 611. | ZN11C08005 | [1] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08005 |
