神钢零件查询(MD300LC) - EXCAVATOR BTW YC0101 - YC0300 (1/80-12/06) (08-029) - RELIEF VALVE, PORT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
153 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24036R77F1 | [1] | VALVE, RELIEF PORT, CONSISTS OF THE FOLLOWING PARTS | VALVE, RELIEF PORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 24036R77F2 | [1] | VALVE PRESSURE RELIE | KOBPORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 24036R77F3 | [1] | VALVE PRESSURE RELIE | KOBPORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 24036R77F4 | [1] | VALVE PRESSURE RELIE | KOBPORT, CONSISTS OF THE FOLLOWING PARTS |
| . . | 24036R77F5 | [1] | VALVE PRESSURE RELIE | KOBPORT, CONSISTS OF THE FOLLOWING PARTS |
| 01. | 24036R77S01 | [1] | BODY, F1 ONLY | |
| 02. | 24036R77S02 | [1] | BODY, F2 - F5 ONLY | |
| 102. | 24036R77S102 | [1] | PLUG | |
| 141. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 142. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 211. | 24036R75S211 | [1] | SPRING | KOB |
| 301. | 24036R75S301 | [1] | SEAT | |
| 311. | 24036R75S311 | [1] | GUIDE, SPRING | |
| 312. | 24036R75S312 | [1] | FILTER | |
| 401. | 24036R75S401 | [1] | POPPET | KOB |
| 511. | 24036R75S511 | [1] | SPRING | KOB |
| 521. | 24036R75S521 | [1] | GUIDE, SPRING | |
| 531. | ZD12P00700 | [1] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 601. | 2436R75S601 | [1] | BOLT, ADJUST | |
| 611. | ZN11C08005 | [1] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08005 |
